DEWALT 20 Gallon Portable Air Compressor, Vertical, V-Twin, 1.6 HP, Model# DXCMLA1682066

Item# 4920162
DEWALT 20 Gallon Portable Air Compressor, Vertical, V-Twin, 1.6 HP, Model# DXCMLA1682066

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

DEWALT 20 Gallon Portable Air Compressor, Vertical, V-Twin, 1.6 HP, Model# DXCMLA1682066

Click or Tap image to Zoom

$779.99

  • Shipping:

    Free shipping (lower 48 states) - Factory shipped

    Heavy/large item. Lift gate service available.

  • Store Pickup:

    Not available - online only
  • One piece cast iron crankcase
  • Thermally stable cast iron cylinder body
  • Automotive-style ball bearings
  • Heavy duty dual voltage induction motor
  • Easy to start and able to drive high pump performance helps to ensure trouble free operation

See full description

Complete Your Solution

  • DEWALT 20 Gallon Portable Air Compressor, Vertical, V-Twin, 1.6 HP, Model# DXCMLA1682066
  • Milton M-Style Air Coupler and Plug Set, 1/4in. NPT, 5-Pc., Model# S-211
Price for all two:

$799.98

Frequently Bought Together

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Accessories

  • Warranty

  • Compare

Product Summary

The DEWALT 20 Gal. Air Compressor is jobsite tough and built for the professional. It features automotive style ball bearings, durable stainless steel reed valves, oil level sight glass, easily accessible oil fill and a cast iron balanced flywheel for easy maintenance, durability and convenience. This single-stage, oil lubricated compressor offers a Twin-V cast iron pump with one piece cast iron crank case and thermally stable cast iron cylinder body. It has a heavy-duty 1.6 HP, 120/240-Volt induction motor, as well as a full-size metal belt guard for added motor protection and durability. For portability, you can wheel it wherever it is needed. DEWALT offers a full line of both electric and gas powered professional compressors. DEWALT compressors include lightweight, portable contractor units, high volume, high capacity wheeled contractor units and high capacity industrial compressors to accommodate the highest demand.

What's Included

    (1) 20 Gal. 155 PSI Single Stage Portable Electric Air Compressor

Features + Benefits

  • One piece cast iron crankcase
  • Thermally stable cast iron cylinder body
  • Automotive-style ball bearings
  • Heavy duty dual voltage induction motor
  • Easy to start and able to drive high pump performance helps to ensure trouble free operation

Key Specs

AttributeSpecification

item#

4920162

Brand

DEWALT

Manufacturer's Warranty

2 year limited warranty

Ship Weight

159.0 LB

Horsepower

1.6 HP

Air Tank Size

20 Gal

Volts

120/240

CFM at 90 PSI

5.3

Max. PSI

155

Stage

1

Engine Start Type

Electric
AttributeSpecification

Pump Material

Cast Iron

CFM at 40 PSI

6.2

Noise Level

78 dB

Oil Required

Yes

Lubrication System

Splash

Pressure Gauge

Yes

Air Dryer

None

Drain Type

Manual

Tank Orientation

Vertical

Product Weight

159.0000 lb

Dimensions L x W x H (in.)

25.0 x 24.5 x 49.0 in

Reviews

Questions & Answers

2 Reviews This action will navigate to reviews.

Questions

1–3 of 3 Questions
Sort by:

  1. What is the duty cycle?

    1 answer

    1. The recommended duty cycle on the compressor is 50%.

      Helpful?

  2. Are all replacement parts available? Pistons, rings, reed valves, check valves etc.

    1 answer

    1. Our sister company, Jacks Small Engines, offers Dewalt replacement parts at www.JacksSmallEngines.com.

      Helpful?

  3. What is the amperage draw on startup when configured to run on 240V?

    1 answer

    1. The air compressor is rated at 7.5 amps at 240 volts and 15 amps at 120 volts.

      Helpful?
