Delavan Cast Iron 6-Roller Pump, 22.8 GPM, 150 PSI, 1,200 RPM Model# 6900C

Item# 27503
Delavan Cast Iron 6-Roller Pump, 22.8 GPM, 150 PSI, 1,200 RPM Model# 6900C

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

Delavan Cast Iron 6-Roller Pump, 22.8 GPM, 150 PSI, 1,200 RPM Model# 6900C

Click or Tap image to Zoom

$179.99

  • Shipping:

  • Store Pickup:

    Not available - online only
  • 22.8 GPM
  • 150 PSI
  • 1,200 RPM
  • 5/8in. solid shaft
  • 3/4in. NPT port female inlet and outlet

See full description

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Accessories

  • Warranty

  • Compare

Product Summary

This Delavan Cast Iron 6-Roller Pump is very useful in a wide variety of applications and industries including agricultural spraying, fluid transfer for mobile equipment, industrial equipment and commercial floor care equipment. It features a compact and lightweight design and can be run by PTO, gas engine or electric driven motors. The dependable Delavan 6900C roller pump utilizes 6 Ultra rollers, Viton seals and a 5/8in. solid shaft. This field-serviceable pump is a direct replacement for the Delavan model 6600C pump.

What's Included

    (1) Pump

Downloads

Product Manual Product Manual2

Features + Benefits

  • 22.8 GPM
  • 150 PSI
  • 1,200 RPM
  • 5/8in. solid shaft
  • 3/4in. NPT port female inlet and outlet
  • Cast iron housing
  • 6 Ultra rollers
  • Viton seals
  • Counterclockwise rotation

Key Specs

AttributeSpecification

item#

27503

Brand

Delavan Pumps

Manufacturer's Warranty

24 months parts/24months labor

Ship Weight

9.89 LB

Material

Cast Iron

Max. PSI

150

Max. Flow Rate

22.8 GPM

Max. Temperature

140 °F

Pump Type

Roller
AttributeSpecification

Volts

12

Max. RPM

1,200

Inlet Port

3/4

Outlet Port

3/4

Shaft Length

1.39 in

Seal Type

Viton

Product Weight

9.0000 lb

Dimensions L x W x H (in.)

x x in

Reviews

Questions & Answers

2 Reviews This action will navigate to reviews.

Questions

1–10 of 14 Questions
Sort by:

  1. Does have pto shaft

    1 answer

    1. The pump features a 5/8" solid stainless steel shaft designed to connect to the tractor's PTO using a separate quick-release PTO coupler.

      Helpful?

  2. Is this pump considered self priming? and what horse power electric motor is needed to run this?

    1 answer

    1. The roller pump is model 6900C is not self priming. It is a manual prime. The pump is designed to be powered by a PTO. This is not able to be attached to an electric motor.

      Helpful?

  3. Can this product be used with pre-emergent herbicide?

    1 answer

    1. The pump can be used with pre-emergent herbicides. It must be flushed out each day with clean water. The pump should never be allowed to run dry.

      Helpful?

  4. Could this pump be used to pump water up out of a pond and into a water trough.

    1 answer

    1. This can pump clear water only. You will need a semi trash pump for your application.

      Helpful?

  5. Does this come with a mounting base/bracket?

    1 answer

    1. This pump does not include a mounting base/bracket.

      Helpful?

  6. Is the pressure adjustable? Does it require a pressure regulator?

    1 answer

    1. The pressure is not adjustable at the pump. A pressure regulator would be needed to regulate or adjust the pressure.

      Helpful?

  7. Will this pump pump hydraulic oil?

    I know this pump will pump water, but would it also work as a hydraulic pump?

    1 answer

    1. This unit can be used to pump hydraulic oil.

      Helpful?

  8. Hello, we are wandering if you have a recommended gas engine that you would couple with this pump. Required HP etc. We would like to run it at 540

    Hello, we are wandering if you have a recommended gas engine that you would couple with this pump. Required HP etc. We would like to run it at 540 RPM or higher and 250-300 psi.
    Thank you in advance.

    1 answer

    1. This pump could not be used with a gas engine. It is to be used with a PTO shaft. It can run at 540-1200 RPM depending on the RPM of your PTO.

      Helpful?

  9. I need a pump that will pump atrazine? Will this pump do that?

    1 answer

    1. The pump will pump atrazine. It is recommended to use nutra-sol to flush out the pump after use.

      Helpful?

  10. If I buy this pump, How do I get a 545 rpm pto adaptor for it?

    1 answer

    1. Northern would not offer a PTO adapter for this pump.

      Helpful?

Warranty

Manufacturer's Warranty

24 months parts/24months labor
