Concentric/Haldex Hydraulic Pump Mounting Bracket

Item# 3042
Concentric/Haldex Hydraulic Pump Mounting Bracket

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

Concentric/Haldex Hydraulic Pump Mounting Bracket

Click or Tap image to Zoom

$79.99

  • Shipping:

    Backordered: Order now to reserve yours -
    Estimated to ship 12/10/26

  • Store Pickup:

    Not available - online only
  • Fits: 10, 11, 16 and 18 HP Briggs STD or IC/IP
  • Fits: 12, 16 and 18 HP Tecumseh
  • Fits: 8, 10 and 11 HP Honda

See full description

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Compare

Product Summary

With Northern's mounting brackets, you can speed assembly time, ensure shaft alignment and improve compactness and appearance at a reasonable price. 2-bolt brackets for Concentric/Haldex 22 and 28 GPM pumps. Fit our items 1057 and 1058 pumps.

Features + Benefits

  • Fits: 10, 11, 16 and 18 HP Briggs STD or IC/IP
  • Fits: 12, 16 and 18 HP Tecumseh
  • Fits: 8, 10 and 11 HP Honda

Key Specs

AttributeSpecification

item#

3042

Brand

Haldex
AttributeSpecification

Ship Weight

4.94 LB

Pump Type

Brackets

Reviews

Questions & Answers

19 Reviews This action will navigate to reviews.

Questions

1–10 of 11 Questions
Sort by:

  1. What is the Pump and Engine Pilot diameter?

    1. 3.25" pump side
      7"engine side

      Helpful?

    2. The pilot diameter of this Concentric/Haldex Hydraulic Pump Mounting Bracket is 3-1/4.”

      Helpful?

  2. what is the pump bolt spacing?

    what is the pump bolt spacing?
    what is the center to center on the 2 bolt holes for mountitng the pump?
    thanks

    1. 4.25" these are S.A.E. if the pump pilot dia. is correct the bolt pattern will be too unless it is a custom pump

      Helpful?

    2. The 2 bolt hole spacing for this pump is 4.18" on center.

      Helpful?

  3. How to tell right length

    Hi how do find out which length pump mounting bracket I need to buy.
    Thank you

    1. You need to mock up the pump you are using to the engine with the LoveJoy or chain coupler you choose. Then just measure the distance between the mounting flange on your engine and the mounting face of your pump.

      Helpful?

    2. To determine the size of pump mounting bracket, you would measure the length of shaft on the engine and length of the shaft on the pump and add 1/2 inch for couplers.

      Helpful?

  4. What connects the pump to the engine shaft

    1. a love-joy coupler or some other brand that allows for the very small amount of misalignment and vibration dampening

      Helpful?

    2. The engine shaft would connect to the pump shaft with a set of two standard half couplings or a set of two heavy duty half couplings that would fit inside the mounting bracket. One half would need to match the diameter of the shaft on the engine, with the other half matching the diameter of the shaft from the pump. Couplings would need to be ordered from the same model type(example, LO95, LO99, LO100 etc). An insert called a spider box would need to go in between the two couplings and would also need to match the model numbers of the couplings themselves.

      Helpful?

  5. Is this a 5-5/8 length?  6.5 inch circle and a 2 hole pump mount with two  4.2 inch bolt hole centers?

    1 answer

    1. The overall length is 6". It has a 4 3/16" bolt circle on the pump side and a 6 1/2" bolt circle on the engine side. It has a pilot hole of 3 1/4".

      Helpful?

  6. Will this bracket work with the heavy duty 2 1/2 couplers?

    1 answer

    1. This bracket can work with the 2-1/2" diameter heavy duty couplers.

      Helpful?

  7. Will this bracket fit a Honda GX270?

    The engine says 9 hp so I assume it will. Thanks!

    1 answer

    1. This bracket will work with a Honda GX270 engine with a 6 1/2" bolt circle.

      Helpful?

  8. What is the length of the bracket ?

    1 answer

    1. The overall length of the Concentric/Haldex pump mounting bracket is 6".

      Helpful?

  9. What is bolt spacing on the engine side of this bracket?

    1 answer

    1. The Concentric/Haldex hydraulic pump has an engine bolt circle of 6 1/2".

      Helpful?

  10. Will this work with item #1014

    1 answer

    1. This Concentric/Haldex Hydraulic Pump Mounting Brackets fits our items 1057 and 1058 pumps (see below.)

      Helpful?
