Edwards Ironworkers Clevis Form Tool Assembly, Model# ED9-HBA100

Item# 7086361
Edwards Ironworkers Clevis Form Tool Assembly, Model# ED9-HBA100

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

Edwards Ironworkers Clevis Form Tool Assembly, Model# ED9-HBA100

Click or Tap image to Zoom

$1679.99

  • Shipping:

    Factory shipped

  • Store Pickup:

    Not available - online only
  • Must have attachment for forming a u-shaped bracket or custom fasteners
  • Requires Clevis Pins to work with the 20 Ton Horizontal Press
  • Simple to mount to the 20 Ton Horizontal Press and easily adjustable to accommodate Clevis Pins from 7/8" to 3-1/2" in diameter

  • Prop 65 Warning: See Details

See full description

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Warranty

  • Compare

Product Summary

The Clevis Form Tool Assembly is a precision-engineered tool designed for creating clevis forms with accuracy and consistency. Ideal for use in manufacturing and mechanical applications, this tool ensures that clevis forms are produced to exact specifications, enhancing the quality and reliability of the final product. Built with durable materials, the Clevis Form Tool Assembly offers long-lasting performance and can withstand the rigors of frequent use in demanding environments. Its user-friendly design allows for easy setup and operation, making it a valuable addition to any workshop or production line. Whether used for custom fabrication or high-volume production, this tool provides the precision and efficiency needed to achieve professional results every time.

What's Included

    (1) 1 ED9-HBA100

Features + Benefits

  • Must have attachment for forming a u-shaped bracket or custom fasteners
  • Requires Clevis Pins to work with the 20 Ton Horizontal Press
  • Simple to mount to the 20 Ton Horizontal Press and easily adjustable to accommodate Clevis Pins from 7/8" to 3-1/2" in diameter

Key Specs

AttributeSpecification

item#

7086361

Brand

Edwards Ironworkers

Manufacturer's Warranty

1 year limited warranty

Ship Weight

1.0 LB

Product Type

Other
AttributeSpecification

Length

6 in

Width

6 in

Product Weight

1.0000 lb

Dimensions L x W x H (in.)

6.0 x 6.0 x 4.0 in

Reviews

Questions & Answers

Questions

Warranty

Manufacturer's Warranty

1 year limited warranty
