California Air Tools, 5 Gal 2 Hp Ultra-Quiet Oil-Free, Horsepower 2 HP, Air Tank Size 5 Gal, Volts 110 Model# 5020W

Item# 6111781
California Air Tools, 5 Gal 2 Hp Ultra-Quiet Oil-Free, Horsepower 2 HP, Air Tank Size 5 Gal, Volts 110 Model# 5020W

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

California Air Tools, 5 Gal 2 Hp Ultra-Quiet Oil-Free, Horsepower 2 HP, Air Tank Size 5 Gal, Volts 110 Model# 5020W

Click or Tap image to Zoom

$398.99

  • Shipping:

    Factory shipped

  • Store Pickup:

    Not available - online only
  • Ultra Quiet - Only 70 decibels
  • Oil-Free Pump – Cleaner air for better tool operation. Less maintenance and Costs.
  • Protective Roll Cage
  • Telescope Handle for adjustable height: 19.5" To 27.5"
  • Easy to Lift and Easy to move around on Job Sites

  • Prop 65 Warning: See Details

See full description

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Warranty

  • Compare

Product Summary

Ideal for any Job Site, the CALIFORNIA AIR TOOLS 5020W Ultra Quiet Oil-Free Rugged Air Compressor is designed to be one of the quietest 2.0 Hp air compressors in the industry having only 70 decibels of sound and features extra large 7.6in. wheels. The Powerful 2.0 HP (SP-9421) motor operates at only 1680 RPM creating less noise and less wear. Motor has been designed to increase duty cycle and allow for longer continuous run times.* The Oil-Free Dual Piston Pump System is engineered for high performance, durability and provides up to 135 PSI. The CAT-5020W Air Compressor has a Oil-Free Dual Piston pump designed to have a life cycle before wear of 3000 Plus hours compared to other comparable air compressors with life cycles of 500 hours or less. The Oil-Free pump allows for use in a variety of temperatures (cold starts) and uneven terrains (no oil in the pump). The Easy Start Valve feature allows for a easier start up using less starting amps. The Easy Start Valve releases a small amount of air from the pump at start up to produce a no-load condition allowing the SP-9421 motor to spin freely. This no-load start up requires less amps for a easier start up in cold temperatures. The large 5.0 Gallon Steel Air Compressor is only 82 pounds making it very easy to move around the jobsite and is lighter and quieter than all competitive models in the same class. Designed for the person looking for Rugged Durability, Power, Air Flow, Less Service and Maintenance with at Least 30% Less Noise! May be used for Air Brushing, Blow Cleaning, Bolting, Brad Nailing, Cutting, Drilling, Finish Nailing, Framing Nailing, Grinding, Hobby Nailing, Hobby Painting, Inflation, Roof Nailing, Sanding, Spraying, Stapling, Surface Prep, Trim and Wrenching.

What's Included

    (2) Large Rugged Flatless Wheels (1) Air Compressor

Downloads

Product Manual
Additional Product Info
Play Item Video

Features + Benefits

  • Ultra Quiet - Only 70 decibels
  • Oil-Free Pump – Cleaner air for better tool operation. Less maintenance and Costs.
  • Protective Roll Cage
  • Telescope Handle for adjustable height: 19.5" To 27.5"
  • Easy to Lift and Easy to move around on Job Sites
  • Large Rugged Flatless Wheels (7.6")
  • Two pressure control gauges
  • Two - Female industrial "Push to Connect" quick connectors
  •  Easy Start Valve - For Less Starting Amperage
  • Thermal Overload Protector
  • Recovery time from 95 PSI to 125 PSI - 20 Seconds
  • 135 PSI  Maximum Pressure
  • 110v / 60 hz
  • Low Amp Draw - 14 Amps
  • Dedicated 15 amp outlet -14 gauge 25ft cord - Min. 5500 Watt Generator
  • Time to fill tank from empty to full - 60 Seconds
  • Recovery time from 95 PSI to 125 PSI - 20 Seconds
  •  L (19.0") x W/D (21") x H (19.5" To 27.5")
  • Limited Warranty 1 Year

Key Specs

AttributeSpecification

item#

6111781

Brand

California Air Tools

Manufacturer's Warranty

1 year limited warranty

Ship Weight

82.0 LB

Horsepower

2 HP

Air Tank Size

5 Gal

Volts

110

Engine Brand

OEM

CFM at 90 PSI

5.3

Max. PSI

135

Stage

1

Air Outlets (qty.)

2

Amps

15

Motor RPM

1,680

Engine Start Type

Electric

Motor Phase

1
AttributeSpecification

Pump Material

Alloy Steel

Air Outlet Size

1/4 in. NPT

CFM at 40 PSI

6.4

Noise Level

70 dB

Oil Required

No

Lubrication System

Oil-Free

Pressure Gauge

Yes

Electronic Drain Valve

No

After Cooler Included

No

Tank Fill Time

1 min

Air Dryer

None

Drain Type

Manual

Tank Orientation

Horizontal

Product Weight

82.0000 lb

Dimensions L x W x H (in.)

19.0 x 21.0 x 41.5 in
