Briggs & Stratton 550 Series Horizontal OHV Engine, 127cc, 3/4in. dia. x 2in.L Shaft, 6:1 Gear Reduction, Model# 83152-1049-F1

Name: Briggs & Stratton 550 Series Horizontal OHV Engine, 127cc, 3/4in. dia. x 2in.L Shaft, 6:1 Gear Reduction, Model# 83152-1049-F1
Brand: Briggs & Stratton
SKU: 26598

Item# 26598

Click or Tap image to Zoom

$608.17

Quantity

Save to List

Shipping:
Factory shipped
Store Pickup:
Not available - online only

OHV design for cooler operation, longer valve life
Dura-Bore™ cast iron cylinder sleeve for extended life
Float carburetor for consistent, easy starting
Maintenance-free Magnetron® electronic ignition for quick, dependable starts
Maxi-Clean™ automotive-style paper air filter for superior protection and long engine life

See full description

Complete Your Solution

Price for all two:

$618.16

Frequently Bought Together

This Item: Briggs & Stratton 550 Series Horizontal OHV Engine, 127cc, 3/4in. dia. x 2in.L Shaft, 6:1 Gear Reduction, Model# 83152-1049-F1$608.17
Honda Power Equipment 10W-30 Motor Oil, 1-Qt. BottleSee Sale Price in Cart

Product Summary

The Briggs Stratton 550 Series Horizontal OHV Engine runs cooler and cleaner, delivering more power, smoother operation, longer engine life and improved fuel economy. An excellent performer with compact design that you can depend on for mid-duty applications.

What's Included

(1) Engine, Model# 83152-1049-F1

Downloads

Product Manual

Additional Product Info

Features + Benefits

OHV design for cooler operation, longer valve life
Dura-Bore™ cast iron cylinder sleeve for extended life
Float carburetor for consistent, easy starting
Maintenance-free Magnetron® electronic ignition for quick, dependable starts
Maxi-Clean™ automotive-style paper air filter for superior protection and long engine life
Dual oil filter and drain
Dual ball bearings reduce wear for long life
DuraLube™ gear-driven splash lubrication continuously supplies oil to all internal parts
Super Lo-Tone Muffler reduces noise level
Not for sale in CA
550 Series, Single Cylinder, Air Cooled, 4-Cycle Gas Engine, 3/4" x 1-13/16" Crankshaft, Model# 83152-1049-F1

Key Specs

Attribute	Specification
item#	26598
Brand	Briggs & Stratton
Manufacturer's Warranty	2 year limited warranty
Ship Weight	35.0 LB
Engine Displacement	127 cc
Engine Type	550 Series
Shaft Diameter	3/4 in
Shaft Length	2 in
Start Type	Recoil
Shaft Keyway	0.18 in
PTO Height	4.17 in
Cylinders (qty.)	1
Cylinder Bore	Cast Iron
Fuel Tank	Yes
Fuel Tank Capacity	2 qt
Oil Capacity	0.625 qt
Low Oil Shutdown	No

Attribute	Specification
Low Oil Alert	No
Shaft Rotation (From PTO Shaft Side)	Counter Clockwise
Governor System	Mechanical
Ignition System	Electronic
Carburetor	Float
Lubrication System	Splash
Bearing Type	Ball
Auto Compression Release	Yes
Cooling System	Air
Bore	2.44 in
Stroke	1.65 in
Air Cleaner Type	Dual Element
Choke Control	Manual
Throttle Control	Manual
Fuel Filter	Yes
Muffler Included	Yes

Reviews

Questions & Answers

: 4 Reviews This action will navigate to reviews.

Questions

1–4 of 4 Questions

13 years ago

Does the gear reduction mean the output shaft is turning at 600 rpm if the engine is rated at 3600rpm?
1. dlhipp

  10 years ago

  yes output shaft of gear box turns at the reduced rate

  Helpful?
2. ProductExpert6

  13 years ago

  Yes, the RPM would be reduced by 6 giving you a reduction to 600 RPM.

  Helpful?
14 years ago

gear reduction on engine shaft or external gear boxshaft
1. dlhipp

  10 years ago

  Reduction is on output of gearbox shaft

  Helpful?
2. ProductExpert12

  14 years ago

  The 6:1 gear reduction is on the engine shaft.

  Helpful?
7 years ago

Can the gear reducer be moved to a different position so that it the output shaft is directly above the crankshaft

1 answer
1. ProductExpert12

  7 years ago

  The gear reduction unit does have a specific location on the engine. We cannot recommend modifying the engine in any way as it could cause damage to the engine and/or would void the warranty.

  Helpful?
14 years ago

Does this model include the geared shaft with the gear reduction

1 answer
1. ProductExpert43

  14 years ago

  This Briggs & Stratton 550 Series Horizontal OHV Engine has a 3/16" shaft key way and a 6:1 Gear Reduction.

  Helpful?
