Brand Hydraulics Log Splitter Valve, Model# PLS755T4JRSH

Item# 2024
"Brand Hydraulics Log Splitter Valve, Model# PLS755T4JRSH"
Top Seller
Brand Hydraulics Log Splitter Valve, Model# PLS755T4JRSH

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

Brand Hydraulics Log Splitter Valve, Model# PLS755T4JRSH

Click or Tap image to Zoom

$134.99

  • Shipping:

    Backordered: Order now to reserve yours -
    Estimated to ship 07/06/26
    $19.99 Same Day

  • Store Pickup:

    1 in stock at Fredericksburg VA - Pickup in under 1 hr

  • Relief valve adjustable to 3,500 PSI, preset at 2,000 PSI
  • Flow rating up to 18 GPM
  • Tandem center; spool action is spring center/hydraulic kickout
  • 4-way directional control; internal adjustable relief
  • 3/4in. NPT inlet and outlet ports; 1/2in. NPT work port

See full description

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Warranty

  • Compare

Product Summary

The Brand Hydraulics log splitter valve is adjustable to 3,500 PSI with a flow rating up to 18 GPM.

What's Included

    (1) Log splitter valve

Downloads

Product Manual

Features + Benefits

  • Relief valve adjustable to 3,500 PSI, preset at 2,000 PSI
  • Flow rating up to 18 GPM
  • Tandem center; spool action is spring center/hydraulic kickout
  • 4-way directional control; internal adjustable relief
  • 3/4in. NPT inlet and outlet ports; 1/2in. NPT work port

Key Specs

AttributeSpecification

item#

2024

Brand

Brand Hydraulics

Manufacturer's Warranty

24 months parts/24months labor
AttributeSpecification

Ship Weight

6.33 LB

Max. PSI

3,500

Reviews

Questions & Answers

33 Reviews This action will navigate to reviews.

Questions

1–10 of 25 Questions
Sort by:

  1. Can this valve be used with a 2 stage pump ?

    1. Yes and that is what I am using now with this valve

      Helpful?

    2. The Brand Hydraulics Log Splitter Valve can be used with a two stage hydraulic pump.

      Helpful?

  2. It is difficult to see the ports names.

    From the picture, you can make out in and out port names, but not the cylinder port names. What port is next to the handle on top of the valve? What port is away from the handle on top of the valve. Please add a spec sheet or picture that shows this information.

    1. They were clearly marked on the one I received.

      Helpful?

    2. The two ports on the top are your cylinder ports, the two on the side are your inlet and outlet ports. You can find a spec sheet at www.brand-hyd.com and look at the product catalog displaying the LS 4 way directional valve.

      Helpful?

  3. With this valve to actuate the hydraulic cylinder I would push the handle towards the valve?

    1 answer

    1. The handle would be pushed forward, towards the cylinder to actuate the cylinder.

      Helpful?

  4. How does the lock splitter work?

    1 answer

    1. The LS valve uses a hydraulic kick-out (pressure‑release detent) to automatically release the control lever when the splitting cylinder reaches the end of its stroke and system pressure rises. That prevents the ram from staying latched against the stop and returns the spool to neutral (or spring center) once the kick‑out pressure is reached.

      Helpful?

  5. info says 4 way directional control. does this mean the handle can be rotated to a different operating position?

    1 answer

    1. The handle can be rotated 180 degrees.

      Helpful?

  6. What are the mounting bolt spacings

    1 answer

    1. The mounting base dimensions are 3.94" L x 1.12" W.

      Helpful?

  7. Can the detent feature be removed so it functions as a basic spring to center from both positions?

    1 answer

    1. The detent feature could be removed, you would need to contact the manufacturer for kit to replace the detent to the spring to center positions. The model PAO7755P4LRS would be this same valve without the detent. At this time, we do not carry that valve.

      Helpful?

  8. How can I adjust the detent? My reverse detent no longer holds on my wood splitter.

    1 answer

    1. There is a jam nut on the opposite end of the handle, you would loosen that out to increase the pressure and screw it in to decrease the pressure.

      Helpful?

  9. Is this valve factory set so we have to hold the handle down to split. Then push it the opposite way,and stay there by itself until the ram retracts all the way?

    1 answer

    1. Yes, that is correct. On this Hydraulic Log Splitter Valve you will need to hold the valve to split and to retract the cylinder in the detented position.

      Helpful?

  10. If the valve is set to detent in both directions (I know it is not recommended for log splitters) will it kick out in both directions?

    1 answer

    1. The valve will kick out in both directions if set to detent in both directions but as you state, doing this is not recommended for log splitter applications.

      Helpful?

Warranty

Manufacturer's Warranty

24 months parts/24months labor
