Ultra-Tow Trailer Axle Spindle, 1-3/4in. Round, 8in.L, Single

Item# 5712454
"Ultra-Tow Trailer Axle Spindle, 1-3/4in. Round, 8in.L, Single"
Top Seller
Ultra-Tow Trailer Axle Spindle, 1-3/4in. Round, 8in.L, Single

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

Ultra-Tow Trailer Axle Spindle, 1-3/4in. Round, 8in.L, Single

Click or Tap image to Zoom

$34.99

  • Shipping:

    Available now
    $19.99 Same Day

  • Store Pickup:

    3 in stock at Fredericksburg VA - Pickup in under 1 hr

  • High-tensile strength steel axle
  • Spindle is precisely machined
  • Spindle must be properly welded to axle tube
  • Includes castle nut, cotter pin and washer

See full description

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Warranty

  • Compare

Product Summary

This heavy-duty Ultra-Tow Trailer Axle Spindle is made from premium high-tensile strength steel. The spindle is machined to extremely close tolerances for durability and long-lasting performance. Each spindle is fully inspected. Sold individually.

What's Included

    (1) Ultra-Tow Trailer Axle Spindle (1) Castle nut (1) Cotter pin (1) Washer

Downloads

Product Manual

Features + Benefits

  • High-tensile strength steel axle
  • Spindle is precisely machined
  • Spindle must be properly welded to axle tube
  • Includes castle nut, cotter pin and washer

Key Specs

AttributeSpecification

item#

5712454

Brand

Ultra-Tow

Manufacturer's Warranty

2 year limited warranty

Ship Weight

4.26 LB

Rated Load

1,750 lb

Overall Length

8 in
AttributeSpecification

Spindle Shape

Round

Spindle Diameter

1-3/4 in

Seal Size

1.72 in

Inner Bearing Size

1.375 in

Outer Bearing Size

1.063 in

Reviews

Questions & Answers

7 Reviews This action will navigate to reviews.

Questions

1–10 of 10 Questions
Sort by:

  1. does this spindle go with ultra pack 572071

    1 answer

    1. This spindle will not match with item 572071. For a hub with a 6 on 5.5" bolt pattern that will match, please see item 6924175 or item 6924132.

      Helpful?

  2. What is the weight maximum

    1 answer

    1. The maximum weight capacity is 1750 pounds.

      Helpful?

  3. Can you get a brake caliper mounting bracket installed on this spindle?

    1 answer

    1. A brake caliper mounting bracket is not available for the spindle.

      Helpful?

  4. Can this spindle be wielded into a 2" axle?

    1 answer

    1. This spindle could be welded into a 2" square axle.

      Helpful?

  5. Can these be welded into box tubing for fishhouse axles?

    1 answer

    1. This can be welded in to a square axle tube.

      Helpful?

  6. What is the length of the unfinished end that will be welded?

    1 answer

    1. The length of the portion of the spindle that is welded to the axle is 3 3/16" long.

      Helpful?

  7. what round tube axle is needed for this spindle

    1 answer

    1. Northern Tool doesn't carry an axle compatible for use with this axle spindle.

      Helpful?

  8. are there 5x4 1/2 hubs available for these spindles?

    1 answer

    1. The item number 57206 is a 5 hole 4.5" bolt circle hub that will work with the spindle.

      Helpful?

  9. Is there a hub available for this spindle that has 4 on 4 studs?

    1 answer

    1. We do not carry a 4 bolt 4 in bolt circle hub that will work with the spindle.

      Helpful?

  10. what bearing set goes with this spindle part #

    1 answer

    1. The bearing kit item number 5712583 will work with this spindle.

      Helpful?

Warranty

Manufacturer's Warranty

2 year limited warranty
