Fostoria Mul-T-Mount Indoor/Outdoor Electric 2-Lamp Infrared Heater, 3.2kW, 480V, 10.922 BTU, Model# 222-60-THSS

Item# 52783
Fostoria Mul-T-Mount Indoor/Outdoor Electric 2-Lamp Infrared Heater, 3.2kW, 480V, 10.922 BTU, Model# 222-60-THSS

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

Fostoria Mul-T-Mount Indoor/Outdoor Electric 2-Lamp Infrared Heater, 3.2kW, 480V, 10.922 BTU, Model# 222-60-THSS

Click or Tap image to Zoom

$878.72

  • Shipping:

    Factory shipped

  • Store Pickup:

    Not available - online only
  • 60° reflective pattern
  • ETL listed for suspended, totally exposed outdoor heating, including ice/snow control
  • ETL listed for indoor high-bay heating and recessed heating
  • 2 lamps, each with coiled tungsten filament within sealed halogen-filled quartz envelope
  • 6in.H temperature pigtail lead wires for hardwire connection

See full description

Complete Your Solution

  • Fostoria Mul-T-Mount Indoor/Outdoor Electric 2-Lamp Infrared Heater, 3.2kW, 480V, 10.922 BTU, Model# 222-60-THSS
  • TPI Wall Mount Brackets for Heater - Stainless Steel, 45° Horizontal Tilt, Compatible with TH and THSS Series, Model# VMB-41-SS
Price for all two:

$1137.92

Frequently Bought Together

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Accessories

  • Warranty

  • Compare

Product Summary

This Fostoria Mul-T-Mount Indoor/Outdoor Electric 2-Lamp Infrared Heater by TPI with a 60° reflective pattern is ETL listed for suspended, totally exposed outdoor heating, including snow/ice control, indoor high-bay heating and recessed heating. Each lamp features coiled tungsten filament within a sealed halogen-filled quartz envelope. 6in.H temperature pigtail lead wires require hardwire connection. 96% radiant delivered efficiency with high moisture and thermal shock resistance. 23-1/2in. mounting center can be mounted horizontally or vertically; requires 3in. clearance from ceiling and 72in. clearance from vertical surface. 8ft.–14ft. recommended indoor mount. Built-in brackets allow for fixture adjustment up to 45° horizontal tilt.

What's Included

    (1) Heater

Features + Benefits

  • 60° reflective pattern
  • ETL listed for suspended, totally exposed outdoor heating, including ice/snow control
  • ETL listed for indoor high-bay heating and recessed heating
  • 2 lamps, each with coiled tungsten filament within sealed halogen-filled quartz envelope
  • 6in.H temperature pigtail lead wires for hardwire connection
  • 96% radiant heat delivered efficiency with high moisture and thermal shock resistance
  • 23-1/2in. mounting center can be mounted horizontally or vertically
  • Requires 3in. mounting clearance from ceiling and 72in. clearance from vertical surface
  • 8ft.–14ft. recommended indoor mount
  • Built-in brackets for fixture adjustment up to 45° horizontal tilt

Key Specs

AttributeSpecification

item#

52783

Brand

Fostoria

Manufacturer's Warranty

1 year limited warranty

Ship Weight

20.0 LB

Heat Type

Infrared

Heat Output

10,922 Btu/hour
AttributeSpecification

Hardwired

Yes

Indoor-Outdoor Use

Indoor and Outdoor

Volts

480

Blower Included

No

Product Weight

lb

Dimensions L x W x H (in.)

24.0 x 15.0 x 10.87 in

Reviews

Questions & Answers

Questions

  1. How large of an area would this heat in a indoor garage area hung from a 10 foot ceiling?

    1 answer

    1. The heater would cover an area of approximately 156 (13L x 12 W) square feet hung from a 10 foot ceiling.

      Helpful?
