TPI Fan-Forced Electric Heater - 5kW, 480V, 17100 BTU, 500 Sq. Ft. Heating Capability, Model# P3P5105CA1N

Item# 53086
TPI Fan-Forced Electric Heater - 5kW, 480V, 17100 BTU, 500 Sq. Ft. Heating Capability, Model# P3P5105CA1N

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

TPI Fan-Forced Electric Heater - 5kW, 480V, 17100 BTU, 500 Sq. Ft. Heating Capability, Model# P3P5105CA1N

Click or Tap image to Zoom

$1127.68

  • Shipping:

    Factory shipped

  • Store Pickup:

    Not available - online only
  • ETL C/US listed for indoor commercial and industrial heating applications
  • Idea for high-bay warehouse facilities, maintenance locations, pole barns, storage and government facilities
  • Designed to deliver spot, supplemental or primary comfort heating system
  • Wall- or ceiling-mount via optional included brackets
  • Totally enclosed in heavy-duty, 18-gauge, powder-coated steel cabinets with hinged and latched compartment for terminal access board

See full description

Complete Your Solution

  • TPI Fan-Forced Electric Heater - 5kW, 480V, 17100 BTU, 500 Sq. Ft. Heating Capability, Model# P3P5105CA1N
  • TPI Line Voltage Thermostat - SPST, Built-In, 45 to 100°F, 25 Amps, Compatible with 5100 Series Heaters, Model# T5100
Price for all two:

$1275.52

Frequently Bought Together

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Accessories

  • Warranty

  • Compare

Product Summary

This TPI Fan-Forced Electric Heater is ETL C/US listed for indoor commercial and industrial heating applications. Ideal for high-bay warehouse facilities, maintenance locations, pole barns, storage and government facilities and other areas that need spot, supplemental or primary comfort heating systems. Designed to mount directly to a wall or ceiling surface via the optional included mounting brackets. Totally enclosed in heavy-duty, 18-gauge, powder-coated steel cabinets with hinged and latched control compartment door for terminal board access. Spiral steel elements with continuously brazed steel fins. 1-speed, ball bearing fan motor with auto reset linear thermal protector. Fan override purges residual heat during shutdown cycles to reduce heat buildup inside housing. Louvers are individually adjustable up to 15° for directional control of airflow.

What's Included

    (1) Heater

Downloads

Product Manual

Features + Benefits

  • ETL C/US listed for indoor commercial and industrial heating applications
  • Idea for high-bay warehouse facilities, maintenance locations, pole barns, storage and government facilities
  • Designed to deliver spot, supplemental or primary comfort heating system
  • Wall- or ceiling-mount via optional included brackets
  • Totally enclosed in heavy-duty, 18-gauge, powder-coated steel cabinets with hinged and latched compartment for terminal access board
  • Spiral steel elements with continuously brazed steel fins
  • 1-speed, ball bearing fan motor
  • Auto reset linear thermal protector
  • Fan override purges residual heat during shutdown to prevent buildup
  • Louvers adjust up to 15° for directional control of airflow

Key Specs

AttributeSpecification

item#

53086

Brand

TPI

Manufacturer's Warranty

1 year limited warranty

Ship Weight

27.0 LB

Heat Output

17,100 Btu/hour

Heating Capability

500 ft²

Heat Type

Forced Air

Hardwired

Yes

Vent-Free

Yes
AttributeSpecification

Assembled Width

14.5 in

Assembled Height

17.75 in

Assembled Depth

6.5 in

Remote Included

No

Thermostat Included

No

Volts

480

Needs Direct Venting

No

Watts

7,500

Reviews

Questions & Answers

Questions

1–3 of 3 Questions
Sort by:

  1. does this need a 220 line

    1 answer

    1. This heater operates on three phase 480 volts.

      Helpful?

  2. Does it have a thermostat control?

    1 answer

    1. This heater does have a thermostat control.

      Helpful?

  3. Is this like a space heater in the wall? Do I need extra circuits in the breaker box in order to use it? Space heaters trip the circuits in both the family room and office in the lower level. Thank you.

    1 answer

    1. The heater will come with a wall/ceiling mount bracket. The heater can be mounted either vertically or horizontally. The heater is three phase 480 volt 6.1 amps per phase. The heater requires a 15 amp circuit protection and 14 AWG wire size.

      Helpful?

Accessories We Recommend

This is a carousel with auto-rotating slides. Activate any of the buttons to disable rotation. Use Next and Previous buttons to navigate, or jump to a slide with the slide dots.

Warranty

Manufacturer's Warranty

1 year limited warranty
