TPI Wall Mount Air Circulator Fan - 24in. Diameter, 5400 CFM, 3-Speed, 1/4 HP, Model# CACU24W

Item# 4229620
TPI Wall Mount Air Circulator Fan - 24in. Diameter, 5400 CFM, 3-Speed, 1/4 HP, Model# CACU24W

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

TPI Wall Mount Air Circulator Fan - 24in. Diameter, 5400 CFM, 3-Speed, 1/4 HP, Model# CACU24W

Click or Tap image to Zoom

$391.68

  • Shipping:

    Factory shipped

  • Store Pickup:

    Not available - online only
  • Commercial air circulator, 24" blade diameter, wall mount, shipped unassembled
  • Operates at 120-Volts generating up to 2.3-amps on single phase
  • Includes 9' long black SJT 3-conductor grounded molded plug
  • All steel construction with a high gloss powder coated black finish
  • Three speed, 1/4-HP direct drive motor constructed of an open ventilated ball bearing, permanent split capacitor and permanently lubricated

See full description

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Warranty

  • Compare

Product Summary

Great value for clean environments such as garages, gyms, and general workstations

What's Included

    (4) Wall mount, grill, blade, & motor

Features + Benefits

  • Commercial air circulator, 24" blade diameter, wall mount, shipped unassembled
  • Operates at 120-Volts generating up to 2.3-amps on single phase
  • Includes 9' long black SJT 3-conductor grounded molded plug
  • All steel construction with a high gloss powder coated black finish
  • Three speed, 1/4-HP direct drive motor constructed of an open ventilated ball bearing, permanent split capacitor and permanently lubricated
  • Pull chain switch to operate the three speeds, fan head is stationary
  • Uses a 24" aluminum 3-paddle blade generating 5,400 CFM's
  • OSHA approved steel spiral wire guards are powder coated with a black finish
  • Grills are designed with retaining clips for easy access to the blade and motor for better maintenance
  • Wall mounting is all steel, with a black finish
  • UL Listed for the USA and Canada

Key Specs

AttributeSpecification

item#

4229620

Brand

TPI

Manufacturer's Warranty

1 year limited warranty

Ship Weight

43.0 LB

Fan Diameter

24 in

Air Delivery

5,400 cfm

Oscillating

No

Volts

120

Outdoor Rated

No

Drive Type

Direct

Assembly Required

Yes

Primary Color

Gray
AttributeSpecification

Noise Level

74 dB

Housing Material

Steel

Secondary Color

Silver

Speeds (qty.)

2

Max. Fan Speed

1,100 rpm

Hardwired

No

Phase

Single-phase

Power Cord Length

9 ft

Watts

210

Product Weight

38.0000 lb

Dimensions L x W x H (in.)

7.0 x 28.0 x 36.0 in

Reviews

Questions & Answers

Questions

  1. can the fan be tilted up and down?

    1 answer

    1. This fan can be tilted up and down from it's mount.

      Helpful?

Warranty

Manufacturer's Warranty

1 year limited warranty
