TOPDON Battery Charger System Analyzer with Printer - 12V/24V, 3.5in. Color Screen, Model# BT600

Item# 5701877
TOPDON Battery Charger System Analyzer with Printer - 12V/24V, 3.5in. Color Screen, Model# BT600

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

TOPDON Battery Charger System Analyzer with Printer - 12V/24V, 3.5in. Color Screen, Model# BT600

Click or Tap image to Zoom

$139.99

  • Shipping:

    Factory shipped

  • Store Pickup:

    Not available - online only
  • 3.5” Color Screen
  • Built-In Thermal Printer
  • Performs Complete Battery, Cranking and Charging Tests
  • Protects Against Electric Shock
  • No Heat Generated

See full description

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Warranty

  • Compare

Product Summary

The BT600 is TOPDON’s advanced non-Bluetooth battery tester for 12V and 24V vehicles. With a 3.5” color screen and a built-in thermal printer, this tool offers the ultimate solution for accurate, fast, and convenient testing. It allows you to view all of your battery data easily and print reports in real-time. The BT600 adopts a cutting-edge conductivity testing technology and includes reverse polarity protection against improper connections. It can measure the actual cold start current capacity of the car’s battery, its state of health and quickly analyze the starter and charging systems.

What's Included

    (1) BT600 Battery Test Cable User Manual 3 rolls of printer paper mini USB cable Carry Bag

Features + Benefits

  • 3.5” Color Screen
  • Built-In Thermal Printer
  • Performs Complete Battery, Cranking and Charging Tests
  • Protects Against Electric Shock
  • No Heat Generated
  • Large, Reinforced, Smoke-Free, & Spark-Free Copper Clamps
  • Quick and Accurate Test Results
  • Supports 12V & 24V Lead-Acid Batteries
  • Reverse Polarity Protection
  • Data Review Function Retrieves the Latest Report

Key Specs

AttributeSpecification

item#

5701877

Brand

TOPDON

Manufacturer's Warranty

1 year limited warranty

Ship Weight

2.65 LB

Product Type

Diagnostic Tool

Display

Color
AttributeSpecification

Battery Type

SLA

Battery Included

No

Battery Required

No

Product Weight

2.6500 lb

Dimensions L x W x H (in.)

9.875 x 3.0 x 9.5 in

Reviews

Questions & Answers

4 Reviews This action will navigate to reviews.

Questions

1–5 of 5 Questions
Sort by:

  1. Does the tester work on all types of batteries? AGM , Lithium?

    1 answer

    1. The BT600 tests 12V lead‑acid batteries only and does not support lithium chemistries.

      Helpful?

  2. Does this charger test the amp output on a alternator ohio

    1 answer

    1. Yes, the TOPDON BT600 model does test the alternator's output as part of its charging system analysis, checking for proper voltage (loaded and unloaded) and ripple under load, but it doesn't directly measure the alternator's amperage output in a standalone current measurement like a clamp meter instead, it confirms the charging system is functioning correctly to meet the vehicle's power demands.

      Helpful?

  3. Does this charger automatically turn on, if the batteries are good, or do I have to manually turn the tester on regardless ? Thanks

    1 answer

    1. This battery charger would have to be manually turned on.

      Helpful?

  4. Does it jump start a dead battery

    1 answer

    1. This battery charger system measures the battery's health, charge, voltage, internal resistance, and Cold Cranking Amps. It does not have the capability to provide the power needed to start an engine.

      Helpful?

  5. Does it give you the CCA of the battery you are testing and does it check alternators?

    1 answer

    1. The BT600 provides the Cold Cranking Amps (CCA) of the battery being tested. It measures the actual CCA capacity of the car’s battery and displays it along with other details like the State of Health (SOH), State of Charge (SOC), voltage, internal resistance, and rating. Additionally, it can check alternators as it supports charging system tests (12V and 24V charging tests) to analyze the performance of the alternator and the charging system.

      Helpful?

Warranty

Manufacturer's Warranty

1 year limited warranty
