Tiger Lights Curved Double Row LED Light Bar - 22in., 7200 Lumens, 120 Watts, Polycarbonate Lens, Model# TLB420C-CURV

Item# 4810879
1 Included
Tiger Lights Curved Double Row LED Light Bar - 22in., 7200 Lumens, 120 Watts, Polycarbonate Lens, Model# TLB420C-CURV

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

Tiger Lights Curved Double Row LED Light Bar - 22in., 7200 Lumens, 120 Watts, Polycarbonate Lens, Model# TLB420C-CURV

Click or Tap image to Zoom

$253.00

  • Shipping:

    Factory shipped

  • Store Pickup:

    Not available - online only
  • 7,200 effective lumens
  • 40 LEDs
  • 22in. x 3in. x 3.5in. (W x H x D)
  • Flood/spot combo beam pattern
  • Curved double row light bar

See full description

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Warranty

  • Compare

Product Summary

This Tiger LED 22in. Curved Double Row Light Bar is an ideal multi-purpose solution to making sure you are seen while out working on every type of terrain. Curved light bars offer an ergonomic design with solid housing. This combination offers better overall night vision by spanning light over more angles for a much wider coverage. Stay safe with a curved light bar. It features a durable polycarbonate lens built to be RoHS compliant, and come with stainless steel hardware. The color of light LED's emit is near the color spectrum of the mid-day sun and allows the human eye to function and view objects better to improve your work environment. Save yourself time and money with LED Lights that are IP68 rated so that no dust will get in your light and your light can be fully and continuously submerged in water, but there will be no side effects. These lights have filters that will eliminate unwanted radio and electromagnetic frequencies from external sources. Their die-cast aluminum housing/heatsink gives them long-lasting durability for a high quality and long service life. Aluminum housing is specifically designed to dissipate heat away from the internal electronics, which increases light output and improves performance. This light is designed to handle any severe environmental condition. Tiger Lights TLB420C-CURV Light Bar. Flood/spot combo beam pattern. 22in. W x 3in. H x 3.5in. D. Curved double row light bar. 7,200 effective lumens. 120 watts. 10 amp draw. 40 LEDs. 3 watt high intensity LED CREE bulbs. Polycarbonate lens. 12V-24V input voltage. Includes heavy-duty stainless steel hardware and mounting brackets. Ideal for agriculture and industrial equipment.

What's Included

    (1) LED Light Bar (1) Connector with Pigtail Wires (1) Set of Mounting Brackets (1) Set of Hardware

Features + Benefits

  • 7,200 effective lumens
  • 40 LEDs
  • 22in. x 3in. x 3.5in. (W x H x D)
  • Flood/spot combo beam pattern
  • Curved double row light bar
  • 120 watts
  • 10 amp draw
  • 3 watt high intensity LED CREE bulbs
  • Durable polycarbonate lens is built to be RoHS compliant
  • Input voltage: 12-Volt to 24-Volt
  • IP68 rating against water and dust
  • Heavy-duty stainless steel hardware
  • Includes mounting brackets and hardware
  • Ideal for Agriculture and Industrial Equipment

Key Specs

AttributeSpecification

item#

4810879

Brand

Tiger Lights

Manufacturer's Warranty

1 year limited warranty

Ship Weight

6.7 LB

Light Type

LED

Lens Color

Clear

Included (qty.)

1

Shape

Rectangle
AttributeSpecification

Connector Type

2-Wire

Bulbs Per Light (qty.)

40

Multi Flash Pattern

No

Lumen Output

7,200

Housing Material

Polycarbonate

Mounting Hardware Included

Yes

Product Weight

6.2500 lb

Dimensions L x W x H (in.)

22.0 x 3.5 x 3.0 in

Reviews

Questions & Answers

Questions

Warranty

Manufacturer's Warranty

1 year limited warranty
