Reliance Generator Plug, 30 Amps, 125/250 Volts, L14-30 Male, Model# L-14-30P

Item# 31212
Reliance Generator Plug, 30 Amps, 125/250 Volts, L14-30 Male, Model# L-14-30P

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

Reliance Generator Plug, 30 Amps, 125/250 Volts, L14-30 Male, Model# L-14-30P

Click or Tap image to Zoom

$19.99

  • Shipping:

    Available now
    $19.99 Same Day

  • Store Pickup:

    7 in stock at Fredericksburg VA - Pickup in under 1 hr

  • 30A 125/250V
  • NEMA L14-30
  • Built-in strain relief
  • UL Listed

See full description

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Warranty

  • Compare

Product Summary

NEMA L14-30 male power cord plug. Max. generator running watts is 7500. Max. generator input is 30A125/250 Volts. Plug is UL listed, impact-resistant. 5-year limited warranty. U.S.A.

What's Included

    (1) Reliance Generator Plug -- 30 Amp, L14-30 Male, Model# L-14-30P

Features + Benefits

  • 30A 125/250V
  • NEMA L14-30
  • Built-in strain relief
  • UL Listed

Key Specs

AttributeSpecification

item#

31212

Brand

Reliance

Manufacturer's Warranty

5 year limited warranty

Ship Weight

0.32 LB

Amps

30
AttributeSpecification

Max. Volts

250

Watts

7,500

Product Type

Plug

UL Listed

Yes

Reviews

Questions & Answers

21 Reviews This action will navigate to reviews.

Questions

1–9 of 9 Questions
Sort by:

  1. Information about product?

    Hello,
    Can you please tell me how many prong is this on have?
    It's doesn't have enought information and picture of it. Thank you.

    1. this plug has 4 prongs

      Helpful?

    2. This is a 4 prong plug.

      Helpful?

  2. Is a 30amp 120-240 plug the same male plug in as a 20amp 120-240 plug

    1. No they are not The little piece that sticks out from the ground plug turns in on the 30 amp and it turns out on the 20 amp. Not interchangeable.

      Helpful?

    2. 20 amp and 30amp plugs have very similar connections, but they are not the same. The 30 amp plug has a tab that turns inward and the 20amp plug has a tab that turns outward. Below under recommendations, you can see the differences.

      Helpful?

  3. i have a generator will this plug work into 4 plug twist need to back up eletric panel when power goes off need to install 220 volts i have 3 wire 10 g wire

    1 answer

    1. This plug has a 4-prong twist lock. It has a max Voltage rating of 250 Volts, and max 30 Amps. It requires a minimum 10 gauge wire.

      Helpful?

  4. What part number is the female to the l1430. I am looking for a plug that I can mount in a wall.

    1 answer

    1. The female plug for the L14-30, would be L14-30C, item #31213.

      Helpful?

  5. Will this connector accept a 6 wire? I am trying to power a distribution box with a 50 amp cord.

    1 answer

    1. This is for 10 gauge wire. We do have a 50 Amp plug for 6 gauge wire (see below).

      Helpful?

  6. wireing pin out

    I was looking for clarification on the pinout of this plug.. I know the l shape is ground! which pin is the neutral/common? I assume the other two would be the two "hot" lines! also how would you suggest the " ground" pin be best used? there is no information in my generators manual regarding this
    thanks much

    1 answer

    1. The neutral/common is directly across from the L shape. The other two are the hot lines. If you are connecting the plug and cord to the generator you do not need to use the ground lug. The plug is grounded through the cord and then the transfer switch and connects to the grounding for the house.

      If you are running the generator with power tools or individually plugging appliances in, you will want to run a wire from the ground lug on the generator to the ground.

      Helpful?

  7. Are these twist lock plugs and are they csa approved

    1 answer

    1. This unit is UL approved with no listing of CSA approval. This unit plugs directly into a receptacle and is a twist lock plug.

      Helpful?

  8. Do you have an Adapter that connects NEMA L14-20P to NEMA L14-30R?

    1 answer

    1. Northern Tool and Equipment does not offer any adapter(s) for the electrical plugs.

      Helpful?

  9. does this come with the ground down

    1 answer

    1. The 30 Amp Reliance Generator Plug does come with a ground. The prong with a slight "L" shape will be the ground.

      Helpful?

Warranty

Manufacturer's Warranty

5 year limited warranty
