Quincy QGS Rotary Screw Air Compressor, Tank Mounted, w/ Dryer, 230V 3-Phase, 20 HP, 132 Gallon, 60.8 CFM, Model# 4152022000

Item# 60428
Quincy QGS Rotary Screw Air Compressor, Tank Mounted, w/ Dryer, 230V 3-Phase, 20 HP, 132 Gallon, 60.8 CFM, Model# 4152022000

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

Quincy QGS Rotary Screw Air Compressor, Tank Mounted, w/ Dryer, 230V 3-Phase, 20 HP, 132 Gallon, 60.8 CFM, Model# 4152022000

Click or Tap image to Zoom

$17,559.00

  • Shipping:

    Free shipping (lower 48 states) - Factory shipped

    Heavy/large item. Lift gate service available.

  • Store Pickup:

    Not available - online only
  • 60.8 CFM @ 125 PSI
  • Continuous 100% duty cycle operation
  • High-efficiency intake filter
  • TEFC electric tri-voltage motor (208V, 230V, 460V)
  • Oil-injected twin screw airend

See full description

Complete Your Solution

  • Quincy QGS Rotary Screw Air Compressor, Tank Mounted, w/ Dryer, 230V 3-Phase, 20 HP, 132 Gallon, 60.8 CFM, Model# 4152022000
  • Quincy Compressor 8,000 Hour Maintenance Kit, For Quincy QGS20 and QGS25 Rotary Screw Compressors, Model# 6229038100
Price for all two:

$18,588.99

Frequently Bought Together

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Accessories

  • Warranty

  • Compare

Product Summary

Quincy QGS Rotary Screw Compressor is a hard-working rotary screw air compressor. Rotary screw compressors are the ideal choice for heavy industrial applications requiring high volumes of compressed air. These energy saving designs are available as base mounted, tank mounted, and with, or without integrated refrigerated dryers. A rotary screw air compressor is a positive displacement compression system that includes a pair of matching helical screws. An oil-flooded rotary screw compressor includes a lubricant that fills the gap between the rotors, which creates an air-tight hydraulic seal and transfers mechanical energy between the two rotors. The air moves through the threads as the screws rotate, and the meshing screws force the air through the compressor. Reduce your energy bill with a 7% to 10% increase in efficiency.

What's Included

    (1) Quincy QGS 20 S rotary screw air compressor

Features + Benefits

  • 60.8 CFM @ 125 PSI
  • Continuous 100% duty cycle operation
  • High-efficiency intake filter
  • TEFC electric tri-voltage motor (208V, 230V, 460V)
  • Oil-injected twin screw airend
  • Standard quiet enclosure
  • Factory-filled 8000 hr premium synthetic fluid
  • Further sound reduction for even quieter operation
  • Full electronic controls with InfoLogic2 software, enabling more flexibility and easier operation
  • 125 PSI
  • 120-gallon ASME certified receiver tank
  • With dryer
  • Pressure change kit available up to 175 PSI (contact your sales representative for more information)
  • Quiet operation at 71dB

Key Specs

AttributeSpecification

item#

60428

Brand

Quincy Compressor

Manufacturer's Warranty

12 months parts/12months labor

Ship Weight

793.0 LB

Horsepower

20 HP

Air Tank Size

132 Gal

Volts

230

Max. PSI

125
AttributeSpecification

Amps

49

Motor Phase

3

Air Outlet Size

3/4 in. NPT

Drain Type

Manual

Tank Orientation

Horizontal

Product Weight

793.0000 lb

Dimensions L x W x H (in.)

76.2 x 25.2 x 57.8 in

Reviews

Questions & Answers

Questions

1–2 of 2 Questions
Sort by:

  1. I just ordered this product...wanted to know what size hose connection the compressor required.

    1 answer

    1. This air compressor has a 3/4" NPT air outlet.

      Helpful?

  2. Is this gear driven? Model# 4152022000 --- looking for rotary gar driven compressor

    1 answer

    1. The QGS-20S is belt driven.

      Helpful?

Accessories We Recommend

This is a carousel with auto-rotating slides. Activate any of the buttons to disable rotation. Use Next and Previous buttons to navigate, or jump to a slide with the slide dots.

Warranty

Manufacturer's Warranty

12 months parts/12months labor
