Prince Tie-Rod Hydraulic Cylinder — 4in. Bore, 12in. Stroke, 3000 PSI, 1 3/4in. Shaft, Model# F400120ABACA07B

Item# 909412
Prince Tie-Rod Hydraulic Cylinder — 4in. Bore, 12in. Stroke, 3000 PSI, 1 3/4in. Shaft, Model# F400120ABACA07B

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

Prince Tie-Rod Hydraulic Cylinder — 4in. Bore, 12in. Stroke, 3000 PSI, 1 3/4in. Shaft, Model# F400120ABACA07B

Click or Tap image to Zoom

$499.99

  • Shipping:

    Factory shipped

  • Store Pickup:

    Not available - online only
  • Heavy duty, high strength tie-rods
  • Induction-hardened piston rod (piston rods on 2" bore not hardened)
  • Ductile iron piston, butt plate, gland, and clevis
  • Urethane u-cup & metal encased wiper (2 1/2 bore and larger models)
  • Crown seal on the piston

See full description

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Accessories

  • Warranty

  • Compare

Product Summary

The Prince Tie-Rod Hydraulic Cylinder is made to handle the most demanding applications. With 70 plus years of American-made know-how they use a high-strength ductile iron piston, butt, gland, and clevis, plus urethane seals in a honed tube that allow them to handle 3,000 PSI continuous working pressure. Aircraft quality paint provides lasting performance. Seal kits are also available (sold separately.)

What's Included

    (1) Tie-rod cylinder

Downloads

Product Manual

Features + Benefits

  • Heavy duty, high strength tie-rods
  • Induction-hardened piston rod (piston rods on 2" bore not hardened)
  • Ductile iron piston, butt plate, gland, and clevis
  • Urethane u-cup & metal encased wiper (2 1/2 bore and larger models)
  • Crown seal on the piston
  • 1" pins & cotter included (Hardened pins on 4", 4.50", and 5" bore models)
  • Standard color is Gloss Black
  • Ports are SAE #8 (3/4-16) extend and retract
  • Nylon piston bearing ring on 4", 4.50", & 5" bore models
  • 3000 PSI
  • Made in USA

Key Specs

AttributeSpecification

item#

909412

Brand

Prince

Manufacturer's Warranty

3 year limited warranty

Ship Weight

53.4 LB

Max. PSI

3,000
AttributeSpecification

Bore Diameter

4 in

Stroke Length

12 in

Shaft Diameter

1.75 in

Closed Pin Center

22.25 in

Reviews

Questions & Answers

1 Review This action will navigate to reviews.

Questions

1–3 of 3 Questions
Sort by:

  1. What Prince model number is this cylidner?

    1 answer

    1. The Prince model number for this cylinder is F400120ABACA07B.

      Helpful?

  2. How do i get a part# for a rebuild kit

    1 answer

    1. Replacement parts and rebuild kits for this cylinder are available through Northern's Parts department. Part numbers for rebuild kits are not available or advertised on our website. Please call 1-800-657-0516 for price and availability. The Parts department is open 7am-6pm Central time, Monday-Friday and 7am-3pm on Saturdays.

      Helpful?

  3. If this Tie-Rod were laying on its side, what is that height?

    The manual has all of the dimensions for the width but non for the height.

    1 answer

    1. The height for this Prince Tie-Rod Cylinder is 5 inches.

      Helpful?

Warranty

Manufacturer's Warranty

3 year limited warranty

Extend Your Warranty Coverage with a Northern Protection Plan (NPP)

Replacement Plan — 1 Year

A Northern Protection Plan is available after adding the product to your shopping cart.
