Optima Scale Tension/Compression Crane Scale, 20,000-Lb. Capacity, 2-Lb. Display Increments, Model# OP-926-20K

Item# 68359
Optima Scale Tension/Compression Crane Scale, 20,000-Lb. Capacity, 2-Lb. Display Increments, Model# OP-926-20K

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

Optima Scale Tension/Compression Crane Scale, 20,000-Lb. Capacity, 2-Lb. Display Increments, Model# OP-926-20K

Click or Tap image to Zoom

$640.25

Choose Options for complete product description, reviews and purchasing.

Capacity

  • Shipping:

    Factory shipped

  • Store Pickup:

    Not available - online only
  • An economical solution to various weighing applications and testing purposes
  • Unsurpassed high resolution in both tension and compression applications
  • Measurement accuracy of better than 0.01% full scale
  • Up to 10 times better than standard crane scales
  • Pre-calibrated with certified test weights per NIST's requirements

See full description

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Warranty

  • Compare

Product Summary

This Optima Scale Tension/Compression Scale is an economical solution to various weighing applications and testing purposes. It features unsurpassed high resolution in both tension and compression applications. With a measurement accuracy of better than 0.01% full scale, it is up to 10 times better than standard crane scales. Pre-calibrated with certified test weights per NIST's requirements, this scale is 0.1-lb. bi-directional for both tension and compression and safe up to 150% overload. The super bright display allows you to read weight at a distance. The load cell is nickel-plated and IP67 corrosion-resistant with a 20ft. cable from load cell to indicator. This scale features auto-zero tracking, net/gross display mode, peak hold, average hold, adjustable motion detection, full-range push-button zero, full-range push-button tare, ABS sealed indicator enclosure and a rechargeable battery.

What's Included

    (1) Tension/compression crane scale (1 load cell, 1 indicator, 2 eye bolts)

Key Specs

AttributeSpecification

item#

68359

Brand

OptimaScale

Manufacturer's Warranty

1 year limited warranty

Ship Weight

32.0 LB

Capacity

20,000 lb

Capacity

20,000 lb

Display Type

LED

Display Type

LED

Measures

lb, kg

Measures

lb, kg
AttributeSpecification

Power Source

240V

Power Source

240V

Battery Included

Yes

Battery Included

Yes

Battery Type

240V

Dimensions L x W x H (in.)

5 x 2 x 7

Product Weight

32.0000 lb

Dimensions L x W x H (in.)

5.0 x 2.0 x 7.0 in

Product Weight

32 lb

Reviews

Questions & Answers

1 Review This action will navigate to reviews.

Questions

1–5 of 5 Questions
Sort by:

  1. Do these have an IP rating for outdoor use ?

    1 answer

    1. This hanging scale has an IP67 rating.

      Helpful?

  2. Is there a resetable max readout? Testing rope breaking strength.

    1 answer

    1. You are able to change it to a resettable maximum readout.

      Helpful?

  3. Does this product come shipped with the NIST Test Certification included?

    1 answer

    1. The scale would not ship with NIST test certification included.

      Helpful?

  4. Does this electronic indicator really use 240 V AC supply current?

    1 answer

    1. The scale would plug into a standard 110/120 volt wall outlet.

      Helpful?

  5. How long is the cable hooked between the cell and the readout instrument?  The sale will be 35 feet in the air

    1 answer

    1. The scale would have a 20 ft cable from the load cell to the indicator.

      Helpful?

Warranty

Manufacturer's Warranty

1 year limited warranty
