NorTrac Hydraulic Kit for Skid Steer Snow Blades

Item# 44733
Top Seller
NorTrac Hydraulic Kit for Skid Steer Snow Blades

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

NorTrac Hydraulic Kit for Skid Steer Snow Blades

Click or Tap image to Zoom

$538.99

  • Shipping:

    Free shipping (lower 48 states) - Factory shipped

  • Store Pickup:

    Not available - online only
  • Lightens your physical workload and lessens downtime
  • Delivers precise angling and maneuvering
  • 2 hydraulic cylinders
  • 2 hydraulic hoses with fittings, washers and pins

  • Prop 65 Warning: See Details

See full description

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Warranty

  • Compare

Product Summary

For use with Item#s 44735, 44705 and 44706, this NorTrac Hydraulic Kit for Skid Steer Snow Blades lightens your physical workload, keeps you in the cab and reduces downtime. Hydraulic adjustment lets you set a precise angle and maneuver around obstacles quickly, so snow ends up exactly where you want it. Kit includes 2 hydraulic cylinders, 2 hydraulic hoses with fittings, mounting pins, cotter pins and washers.

What's Included

    (2) Hydraulic cylinders (2) Hydraulic hoses with fittings (1) Set of mounting pins, cotter pins and washers

Features + Benefits

  • Lightens your physical workload and lessens downtime
  • Delivers precise angling and maneuvering
  • 2 hydraulic cylinders
  • 2 hydraulic hoses with fittings, washers and pins

Key Specs

AttributeSpecification

item#

44733

Brand

NorTrac

Manufacturer's Warranty

1 year limited warranty

Ship Weight

35.0 LB
AttributeSpecification

Material

Steel

Product Type

Hydraulic Kit

Mounting Hardware Included

Yes

For Use With

Nortrac Skid Steer Blade

Reviews

Questions & Answers

2 Reviews This action will navigate to reviews.

Questions

1–7 of 7 Questions
Sort by:

  1. Are the cylinders double action?

    How are the cylinders hooked up? Opposite so o be pushes while the other pulls in?

    1. Yes, opposite. Place the "T" fittings at the base of each cylinder. Connect the hoses to the T fittings and then to the stroke end of the opposite cylinder so that the hoses form an "X".

      Helpful?

    2. These cylinders are double acting and are designed to be installed onto our item#'s 44705 and 44706. The double acting means that the hydraulic pump/motor flows the hydraulic fluid alternately on each side of the hydraulic cylinder piston.

      Helpful?

  2. Hi there - What are the minimum and maximum pin center-to-center distances of these cylinders when they are fully retracted / extended?

    1 answer

    1. The closed pin center is 14" and the open pin center is 20.5".

      Helpful?

  3. What is the length of the hoses

    1 answer

    1. The included hoses are 18 inches long. They connect the two cylinders together for proper operation. The hoses to connect the cylinders to the hydraulic system are not included.

      Helpful?

  4. What size are the T fittings? 3/8 or 1/2 inch? I will be hooking into 1/2 inch lines on a third function loader valve on an ag tractor. Thanks

    1 answer

    1. The T fittings are 3/8''.

      Helpful?

  5. Do you need to use a cushion/crossover relief valve with these?

    1 answer

    1. This hydraulic kit does not require a cushion/crossover relief valve to be used with it.

      Helpful?

  6. What is the collapsed length of the cylinder?

    1 answer

    1. The closed pin distance is 14" eye center to eye center.

      Helpful?

  7. What are the dimensions of the cylinders, stroke, attachment points

    1 answer

    1. The cylinder has a 2" bore with a 6 1/2" stroke, the mounting pin holes are 1".

      Helpful?

Warranty

Manufacturer's Warranty

1 year limited warranty
