Valley Industries Quick-Connect Pressure Gauge, 5,000 PSI, 3/8in.

Item# 32154
"Valley Industries Quick-Connect Pressure Gauge, 5,000 PSI, 3/8in."
Top Seller
Valley Industries Quick-Connect Pressure Gauge, 5,000 PSI, 3/8in.

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

Valley Industries Quick-Connect Pressure Gauge, 5,000 PSI, 3/8in.

Click or Tap image to Zoom

$32.99

  • Shipping:

    Backordered: Order now to reserve yours -
    Estimated to ship 07/10/26

  • Store Pickup:

    Not Available
  • Ideal for agriculture, hydraulics, utility, and more
  • Accurately measures pressure from 0-5000PSI
  • Single scale PSI face for a clean, easy-to-read display
  • Glycerin-filled setup that provides vibration damping, reduces wear and tear, & improves accuracy
  • Stainless steel casing for long-lasting durability in harsh environments

See full description

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Warranty

  • Compare

Product Summary

The NorthStar® Pressure Washer Pressure Gauge has a 5000 PSI range and a large, easy-to-read face. Attaches quickly and easily to pressure washer outlet. Accuracy ASME/ANSI B40.1 Grade B (3-2-3%).

What's Included

    (1) Pressure Gauge

Features + Benefits

  • Ideal for agriculture, hydraulics, utility, and more
  • Accurately measures pressure from 0-5000PSI
  • Single scale PSI face for a clean, easy-to-read display
  • Glycerin-filled setup that provides vibration damping, reduces wear and tear, & improves accuracy
  • Stainless steel casing for long-lasting durability in harsh environments
  • Helical bourdon tube made from phosphor bronze, providing excellent durability & corrosion resistance
  • IP65 rated for protection against dust and water, ensuring reliability in tough conditions
  • Operates efficiently between 32°F to 150°F, ensuring reliable performance in cold and hot environments
  • Compact 2.5" diameter face that is clear and easy-to-read pressure measurements
  • Simple to clean and maintain, with a durable design that minimizes the need for frequent service
  • Backed by a one-year manufacturer warranty

Key Specs

AttributeSpecification

item#

32154

Brand

Valley Industries

Manufacturer's Warranty

1 year limited warranty

Ship Weight

0.77 LB

Case Material

Stainless Steel

Min. Operating Pressure

0 PSI

Max. Operating Pressure

5,000 PSI

Gauge Diameter

2.5 in

Connection Size

0.38 in

Bourdon Tube

Phosphor Bronze

Pointer Material

Aluminum
AttributeSpecification

Connection Type

Male

Connection Material

Brass

Dial Material

Aluminum

Window Material

Acrylic

Fill Material

Glycerin

Movement

Clockwise

Accuracy

Meets ASME/ANSI B40.1 Grade B standards with an accuracy of ±3-2-3% of full scale, ensuring precise pressure measurements

Gauge Application

Ideal for agriculture, hydraulics, utility, and more

Mounting Type

Stem

Product Weight

0.8000 lb

Dimensions L x W x H (in.)

4.75 x 2.5 x 7.0 in

Reviews

Questions & Answers

75 Reviews This action will navigate to reviews.

Questions

1–9 of 9 Questions
Sort by:

  1. The gauge comes with the quick connection?

    so it will connect right to the quick connector on the pressure washer? Pressure Washer #1578202.

    1. The gauge will come with 3/8" quick coupler fittings.

      Helpful?

    2. yes...quick disconnects each side

      Helpful?

    3. Just snap it on and your good to go!

      Helpful?

    4. Yes!

      Helpful?

    5. Yes, it is a standard 3/8" pressure washing quick connector fitting, just like the end of your high pressure hose. You need to connect the gauge to the machine first, then your hose to the gauge and so forth.

      Helpful?

  2. Can i leave this gauge on pressure washer permantly? Or is that not a good idea?

    1. The gauge can be left on the pressure washer permanently.

      Helpful?

    2. I leave my gauge on the machine all the time. Every once in a while I remove it to spray a little WD-40 in it to keep the ball bearings on the female side lubed.

      Helpful?

    3. YES

      Helpful?

    4. Yes you can leave on permenately. The gauge is oil filled and will last for years.

      Helpful?

  3. Does this gauge have to be mounted vertically?

    Based on my current frame for my pressure washer it would be much easier to read if it was horizontal to the ground so I could look down and read the PSI while the unit was running. Is this possible with this type of gauge or does it have to be mounted vertically to the ground?

    1. The pressure washer gauge can be mounted in any position including horizontally or face up/face down.

      Helpful?

    2. Doesn't matter as long as the little rubber plug in the top of the gauge doesn't leak out the oil in the gauge.

      Helpful?

    3. ANY DIRECTION

      Helpful?

    4. no

      Helpful?

  4. What is the direction of the water flow?

    Just looking for the general direction of the water flow on this unit? Is it going from the male to female end or female to male end?

    1. This quick connect gauge works regardless of the water flow direction, meaning the water can flow from the male to female end or vice versa.

      Helpful?

    2. This gauge will work with the water flow in either direction.

      Helpful?

  5. what's the gauge diameter? what kind of liquid is in the gauge? thanks

    what's the gauge diameter? what kind of liquid is in the gauge? thanks

    1. The gauge will have a face diameter of 2.5". The gauge is 4.5" tall from top to bottom including the coupler. The gauge is glycerin filled.

      Helpful?

    2. Gauge diameter is 2½", Liquid appears to be some kind of clear oil.

      Helpful?

  6. do you pull the trigger on the gun to read the pressure gauge or not

    1 answer

    1. The gauge will be mounted to the outlet of the pump. It will read some pressure while the pump is in bypass. To know what pressure is being sprayed, the trigger will need to be engaged.

      Helpful?

  7. Where is this guage made,Country

    1 answer

    1. The gauge is manufactured in Taiwan.

      Helpful?

  8. Is it best to connect his to the pump side or can I connect it to the gun?

    I need to be able to see the pressure at all times.

    1 answer

    1. The gauge is recommended to be attached to the pump outlet.

      Helpful?

  9. Is this a liquid fillable gauge?

    Picture shows gauge half filled with glycerin or mineral oil. Can the gauge be user filled?

    1 answer

    1. This is a glycerin filled gauge. It is not recommended for glycerin filled gauges to be filled completely. They are designed to have a small air space or gap to allow expansion and contraction of the liquid due to temperature changes and pressure fluctuations. The gauge is refillable.

      Helpful?

Warranty

Manufacturer's Warranty

1 year limited warranty
