Milwaukee Compact Electromagnetic Drill Press, 1-5/8in. Drill Capacity, 13 Amp, 2.3 HP, Model# 4272-21

Name: Milwaukee Compact Electromagnetic Drill Press, 1-5/8in. Drill Capacity, 13 Amp, 2.3 HP, Model# 4272-21
Brand: Milwaukee
SKU: 51685

Item# 51685

"Milwaukee Compact Electromagnetic Drill Press, 1-5/8in. Drill Capacity, 13 Amp, 2.3 HP, Model# 4272-21"

Top Seller

Click or Tap image to Zoom

$1299.00

Quantity

Save to List

Shipping:
Free shipping (lower 48 states) - Available now
Store Pickup:
Not available - online only

Magnetic base operates with electricity
Powerful 13 Amp motor
Tool-free adjustment: cutter to twist bit
Optimized cutting and drilling speeds
Strongest magnetic hold on 1/4 in. steel

See full description

Complete Your Solution

Price for all three:

$1783.98

Frequently Bought Together

This Item: Milwaukee Compact Electromagnetic Drill Press, 1-5/8in. Drill Capacity, 13 Amp, 2.3 HP, Model# 4272-21$1299.00
Milwaukee Annular Cutter Kit, 9-Pc., Model# 49-22-8410$469.99
Ironton Impact-Duty Titanium SAE Drill Bits, 15-Pc.$14.99

Product Summary

The Milwaukee 1-5/8” Electromagnetic Drill delivers the faster set-up, cutting and drilling. It’s 13 amp motor delivers the fastest drilling w/ annular cutters or twist drill bits. Equipped with a 2-speed gear box the tool can be adjusted tool-free between annular cutters at 475RPM and twist drill bits at 730 RPM.

What's Included

(1) 1-5/8" Electromagnetic Drill Kit (4272-21) (1) Safety Strap (1) Lubrication Spray Bottle (1) Chuck Key (1) Carrying Case (1) 3/4” Weldon to ½” Chuck adapter (2) 1” Retractable Pilot Pin

Downloads

Product Manual Product Manual2

Features + Benefits

Magnetic base operates with electricity
Powerful 13 Amp motor
Tool-free adjustment: cutter to twist bit
Optimized cutting and drilling speeds
Strongest magnetic hold on 1/4 in. steel
Tool free motor head adjustment
3/4 in. weldon quick change arbor
2-speed gear box: 475/730 RPM
Auto-stop lift-off detection
Tool free feed-handle

Key Specs

Attribute	Specification
item#	51685
Brand	Milwaukee
Manufacturer's Warranty	5 year limited warranty
Ship Weight	48.2 LB
Drilling Capacity	1-5/8 in
Horsepower	2.3 HP
Volts	120
Amps	13 A

Attribute	Specification
Cordless	No
Tool Only	No
Chuck Type	Keyed in
Chuck Size	3/4 in
Max. Speed	690 rpm
Storage Type	Case
Variable Speed	Yes
Batteries Included	No

Reviews

Questions & Answers

Questions

1–10 of 20 Questions

2 months ago

what is the height of it

1 answer
1. ProductExpert11

  2 months ago

  The dimensions on the drill press is 11.25" L x 7.5" W x 15.5" H.

  Helpful?
4 months ago

What’s the largest annular cutter that fits on the drill?

1 answer
1. ProductExpert6

  4 months ago

  The drill press will accept a maximum annular cutter diameter of 1 5/8".

  Helpful?
10 months ago

Hi! What a the shipping box size?

1 answer
1. ProductExpert6

  9 months ago

  The shipping dimensions are 30" L x 9" W x 22" H.

  Helpful?
2 years ago

what kind of drill bits are needed for this drill?

1 answer
1. ProductExpert23

  2 years ago

  For the Milwaukee Compact Electromagnetic Drill Press (Model 4272-21), you can use twist drill bits and annular cutters. The drill has a 3/4" Weldon quick change arbor and a 2-speed gear box that allows for tool-free adjustment between annular cutters at 475 RPM and twist drill bits at 730 RPM.

  Helpful?
3 years ago

how do I put the 1/2" chuck in?

1 answer
1. ProductExpert5

  3 years ago

  To change the chucks, twist the drill chuck arbor and insert the new chuck.

  Helpful?
3 years ago

Is the mag base flat or "V"d. That is can I mount to a pole?

1 answer
1. ProductExpert6

  3 years ago

  The base on the drill press would be flat.

  Helpful?
4 years ago

is this new or reman?

1 answer
1. ProductExpert37

  4 years ago

  This drill press is sold as brand new.

  Helpful?
4 years ago

What style of shank is needed for this drill? can I use any brand of cutter?

1 answer
1. ProductExpert12

  4 years ago

  This drill press uses 3/4" Weldon shanks. Any brand can be used as long as it has the correct fitting.

  Helpful?
4 years ago

I am looking to use a Mag base drill to drill out the suspension bracket rivets in a truck frame. What is the distance from the edge of the base to the centerline of the drill bit?

1 answer
1. ProductExpert30

  4 years ago

  The height from the base to the centerline of the drill bit is 8.40".

  Helpful?
4 years ago

Is it OSHA compliant?

1 answer
1. ProductExpert6

  4 years ago

  The drill press would not be OSHA compliant. It is UL listed.

  Helpful?
