Milwaukee 1-Piece SDS-MAX Core Bit, 4in. x 11 3/8in., Model# 48-20-5432

Item# 111963
"Milwaukee 1-Piece SDS-MAX Core Bit, 4in. x 11 3/8in., Model# 48-20-5432"
1 Included
Milwaukee 1-Piece SDS-MAX Core Bit, 4in. x 11 3/8in., Model# 48-20-5432

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

Milwaukee 1-Piece SDS-MAX Core Bit, 4in. x 11 3/8in., Model# 48-20-5432

Click or Tap image to Zoom

$215.00

  • Shipping:

    Free shipping (lower 48 states) - Available now
    $19.99 Same Day

  • Store Pickup:

    2 in stock at Fredericksburg VA - Pickup in under 1 hr

  • Drift key (48-20-5497) sold separately for easy centering bit removal
  • Ideal for brick, block, and concrete applications
  • Designed for SDS Max rotary hammers
  • Drilling depth of 3"
  • Asymmetrical and Alternating Teeth for up to 20% faster drilling speeds

See full description

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Compare

Product Summary

Milwaukee's one piece carbide tipped core bits are ideal for drilling large holes in brick, block, and concrete. The asymmetric tooth pitch with alternating tooth geometries for up to 20% faster drilling speeds. The one piece design maximizes energy transfer and the thick wall core body is durable in large hammers. The fluted core exterior minimizes friction loss and removes debris faster. Core bit cut with the outer cutting edge only. The inside core must be removed to allow for deeper hole drilling applications beyond 3in. Centering bit 48-20-5495 (included) is recommended for exact spot drilling and to avoid bit wandering during use. The drift key 48-20-5497 (not included) allows for easy removal of the centering bit. The one piece core bits are available in SDS-Max or Spline shanks, ranging from 1-1/2in. to 6in. diameters and overall lengths of 11-3/8in. or 22in., with a drilling depth of 3in.

What's Included

    (1) Bit

Features + Benefits

  • Drift key (48-20-5497) sold separately for easy centering bit removal
  • Ideal for brick, block, and concrete applications
  • Designed for SDS Max rotary hammers
  • Drilling depth of 3"
  • Asymmetrical and Alternating Teeth for up to 20% faster drilling speeds
  • Thick-Wall Core Body for Durability Even in Large Hammers
  • Includes centering bit (48-20-5495) to allow exact spot drilling and reduce bit walking

Key Specs

AttributeSpecification

item#

111963

Brand

Milwaukee

Ship Weight

3.72 LB

Size (SAE)

4 in

Included (qty.)

1

Measurement Standard

Standard (SAE)

Bit Material

Carbide
AttributeSpecification

Bit Type

Masonry, Glass + Tile Bits

Set

No

Shank Style

SDS Max

Bit Length

11.37 in

Drilling Material

Concrete

Storage Type

None
