LiquiDynamics DEF IBC Tote System, Air, Manual Shutoff Nozzle, Model# 970012-06M

Item# 21993
LiquiDynamics DEF IBC Tote System, Air, Manual Shutoff Nozzle, Model# 970012-06M

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

LiquiDynamics DEF IBC Tote System, Air, Manual Shutoff Nozzle, Model# 970012-06M

Click or Tap image to Zoom

$1105.99

  • Shipping:

    Factory shipped

  • Store Pickup:

    Not available - online only
  • Closed-design and self-priming pump minimize possible contamination or dilution of DEF fluid
  • Convenient hanger and dry break fluid connection allows system to be quickly and easily moved from one tote to the next
  • Electronic meter provides a digital readout of the amount dispensed
  • Meter has a re-settable batch total, a re-settable cumulative total and a non re-settable cumulative total
  • Polypropylene manual nozzle shuts off flow manually

See full description

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Accessories

  • Warranty

  • Compare

Product Summary

This LiquiDynamics Diesel Exhaust Fluid (DEF) Tote System with a manual nozzle provides a convenient and secure way to transfer DEF when using compressed air. High-quality system is designed to function as a closed system when used with an appropriate coupler (sold separately). U.S.A.

What's Included

    (1) Tote system

Features + Benefits

  • Closed-design and self-priming pump minimize possible contamination or dilution of DEF fluid
  • Convenient hanger and dry break fluid connection allows system to be quickly and easily moved from one tote to the next
  • Electronic meter provides a digital readout of the amount dispensed
  • Meter has a re-settable batch total, a re-settable cumulative total and a non re-settable cumulative total
  • Polypropylene manual nozzle shuts off flow manually
  • Includes a self-priming 14 GPM air operated double diaphragm pump, 3/4in. x 4-ft. suction hose, 3/4in. x 12in. discharge hose, electronic digital turbine meter, polypropylene manual shutoff nozzle and convenient pump hanger plate with nozzle holder and drip cup
  • For 275 or 330-gallon totes
  • Requires mated closed system coupler to match suction valve

Key Specs

AttributeSpecification

item#

21993

Brand

LiquiDynamics

Manufacturer's Warranty

1 year limited warranty

Ship Weight

60.0 LB
AttributeSpecification

Max. Flow

840 GPH

Inlet Port

3/4 in

Product Weight

lb

Dimensions L x W x H (in.)

9.0 x 12.0 x 15.0 in

Reviews

Questions & Answers

Questions

1–3 of 3 Questions
Sort by:

  1. So you can't use this on glycol?

    1 answer

    1. The tote system cannot be used on glycol. It is for DEF only.

      Helpful?

  2. Can this system be used to pump caustic?

    1 answer

    1. This tote system could not be used to pump caustic materials. It is for DEF only.

      Helpful?

  3. what is the maximun CPS that will handle this pump?

    1 answer

    1. There is no established centipoise rating for this pump.

      Helpful?

Warranty

Manufacturer's Warranty

1 year limited warranty
