Lincoln Electric, WELD-PAK 180I WELDER W/ SPOOL, Max. Amps 180 Mig Ready, Model# K5387-6

Item# 115001
"Lincoln Electric, WELD-PAK 180I WELDER W/ SPOOL, Max. Amps 180 Mig Ready, Model# K5387-6"
Lincoln Electric, WELD-PAK 180I WELDER W/ SPOOL, Max. Amps 180 Mig Ready, Model# K5387-6

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

Lincoln Electric, WELD-PAK 180I WELDER W/ SPOOL, Max. Amps 180 Mig Ready, Model# K5387-6

Click or Tap image to Zoom

$1429.99

  • Shipping:

    Free shipping (lower 48 states) - Factory shipped

  • Store Pickup:

    Not available - online only
  • Multi-Process Welder: MIG weld, Flux-Core weld, TIG weld and Stick weld
  • TIG - Torch and Foot pedal not included; Wide 10-165 amp range permits welding on thin and thick steel and stainless
  • MIG - Wide 30-180 amp welding output for MIG, FCAW and Spool Gun allows for welding 24 gauge to 3/8" welding material
  • Stick - Smooth arc starts prevent stick. Heavy duty electrode holder and cable included
  • Perfect for the shop, farm, home or auto body shops

  • Prop 65 Warning: See Details

See full description

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Warranty

  • Compare

Product Summary

120 or 230 VOLT AC INPUT COMPACT MULTI-PROCESS WELDER Requiring common 120 volt input power or 230 volt input power, the WELD PAK® 180i MP DV can be used almost anywhere. With simple two knob control, the machine is easy to set up for gasless flux-cored welding for deep penetration on thicker steel, gas-shielded MIG welding on thin gauge steel, stainless or aluminum, stick welding or DC TIG welding. The Lincoln Electric WELD PAK® 180i MP DV is an excellent choice! Enhanced Durability Fully adjustable drive system reduces the chance of wire tangling and crushing. Brass-to-brass gun connection enhances conductivity. Durable cast aluminum gear box delivers added drive torque and quiet operation. Easy-turn numeric drive tension indicator identifies optimized ranges for different wire types. Capable Performance Forgiving arc makes dialing in your application easy. Smooth arc starts with minimal spatter. Wide 20-180 amp welding output range for MIG, FCAW and Spool Gun Wide 10-165 amp welding output range for DC TIG Wide 25 to 160 amp welding output range for Stick MIG weld 24 gauge up to 5/16in. sheet metal in a single pass. Weld up to 5/16in. steel using self-shielded Lincoln Electric NR-211-MP wires. Stick weld to 3/16in. (4.8 mm), and TIG weld to 1/8in. (3.1 mm). Optional TIG torch sold separately Optional foot pedal for remote control of weld output while TIG welding sold separately Includes: Spool gun for MIG welding aluminum Compact Design Lightweight and portable at 34.5 lbs Conveniently plugs into household 230 volt or 120 volt power with included adaptor.

What's Included

    (1) Magnum Pro 100L gun and 10ft. (3.0m) cable assembly with brass connection and 8-pin trigger connector (K530-7) (1) .025in. (0.6mm) contact tip (1) .030 (.7mm) contact tip (1) .035 in. (0.9mm) contact tip (1) Gasless nozzle for Innershield welding (KH726) (1) Gas nozzle for MIG welding (KH725) (1) Spindle adapter for 10-lb. and 12.5-lb. spools (KH720) (1) .025-.035in. (0.6-0.9mm) wire diameter dual track drive roll for MIG and flux-cored welding (KP2948-1) (1) Shielding gas regulator and hose (KH738) (1) Work clamp and 10ft. (3.0m) cable (1) Electrode holder with 10ft. cable (1) Spool gun (1) Instruction manual

Downloads

Product Manual Product Manual2
Play Item Video

Features + Benefits

  • Multi-Process Welder: MIG weld, Flux-Core weld, TIG weld and Stick weld
  • TIG - Torch and Foot pedal not included; Wide 10-165 amp range permits welding on thin and thick steel and stainless
  • MIG - Wide 30-180 amp welding output for MIG, FCAW and Spool Gun allows for welding 24 gauge to 3/8" welding material
  • Stick - Smooth arc starts prevent stick. Heavy duty electrode holder and cable included
  • Perfect for the shop, farm, home or auto body shops
  • Recommended Accessories: Contact Tips (KH710. KH711, KH712), Welding Nozzles (KH725, KH726), Mild Steel MIG Wire (ED030631), Flux-Core MIG Wire (ED030584), Anti-Spatter Spray (KH505), Nozzle Gel and Portable Welding Cart (K2275-3)
  • Performance forgiving arc makes dialing your application easy
  • Smooth arc starts with minimal splatter
  • Wide 20-180 Amp welding output range for MIG, FCAW and Spool Gun
  • Wide 10-165 Amp welding output for DC TIG
  • Wide 25-160 Amp welding output range for Stick
  • MIG weld 24-gauge up to 5/16in. sheet metal in a single pass
  • Weld up to 5/16in. steel using self-shielded Lincoln Electric NR-211-MP wires
  • Stick weld to 3/16in. (4.8mm); TIG weld to 1/8in. (3.1mm)
  • Includes spool gun for MIG welding aluminum
  • Optional foot pedal for remote control of weld output while TIG welding (sold separately)
  • Optional TIG torch (sold separately)

Key Specs

AttributeSpecification

item#

115001

Brand

Lincoln Electric

Manufacturer's Warranty

3 year limited warranty

Ship Weight

47.0 LB

Volts

120/230

Max. Amps

180

Power Type

DC

Multi-process

Yes

Spool Gun Included

Yes

Welding Processes

Flux-Core, MIG, Stick, TIG

Max. Weld Thickness

0.375 in

Max. Welding Wire Diameter

0.035 in

Duty Cycle

Mig: 30% At 165a, Tig: 30% At 165a, Stick: 25% At 160a
AttributeSpecification

Weldable Materials

Steel, Stainless Steel, Aluminum

Min. Amps

10

Wire Feed Speed Control

Yes

Cart Included

No

Mig Ready

Yes

Power Cord Length

10 ft

Clamp Cable Length

10 ft

Electrode Cable Length

10 ft

Regulator and Gas Hose Included

Yes

Shielding Gas Required

No

Product Weight

15.6000 lb

Dimensions L x W x H (in.)

13.6 x 8.9 x 18.1 in

Reviews

Questions & Answers

2 Reviews This action will navigate to reviews.

Questions

1–2 of 2 Questions
Sort by:

  1. Can this welder be used on a 20 amp circuit 120 volts in my shop

    1 answer

    1. The recommended voltage is 120/1/60 or 230/1/60. The input amperage is 15 amps. Breaker size required is 20 amps.

      Helpful?

  2. Do we use gas with non flux core welding? Like with MIG welding, we use gas, correct?

    1 answer

    1. You would not need to use gas with non-flux core welding. It would depend on what you are welding for MIG welding if gas is required. It is not required for all MIG welding. The gas does help to protect the weld pool from the surrounding environment. A mixture of argon and carbon dioxide would be used to shield the weld pool.

      Helpful?

Warranty

Manufacturer's Warranty

3 year limited warranty
