Laguna Revo 12|16 Lathe - 1 HP, 12.5in. Swing Over Bed, 16in. Between Centers, Model# 12|16

Item# 6009612
Laguna Revo 12|16 Lathe - 1 HP, 12.5in. Swing Over Bed, 16in. Between Centers, Model# 12|16

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

Laguna Revo 12|16 Lathe - 1 HP, 12.5in. Swing Over Bed, 16in. Between Centers, Model# 12|16

Click or Tap image to Zoom

$1290.99

  • Shipping:

    Free shipping (lower 48 states) - Factory shipped

  • Store Pickup:

    Not available - online only
  • 1 HP DC Permanent Magnet Motor
  • Pulse Width Modulation (PWM) Controller
  • 1HP, 110V Motor
  • 12? Swing Over Bed
  • 16? Between Centers

  • Prop 65 Warning: See Details

See full description

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Warranty

  • Compare

Product Summary

The definitive midi-lathe, Laguna’s REVO 12|16 encapsulates the prestige of Laguna in a small package. Featuring a Pulse Width Modulation system motor to maintain consistent torque at any speed, one step cam-action belt change with magnetic door housing, and a luxury banjo w/45º chamfered edge. The 1216 controls the 1hp DC motor using pulse width modulation. A big problem with DC motor control is torque in the low speeds, and you will find many MIDI lathes with the lowest speed of 250RPM and higher because of this. This is because the cost effect controllers introduce resistance into the voltage to limit the power, which reduces the speed but also reduces the torque at the same rate. PWM will deliver full torque across the entire speed range. This allows for tremendous torque in low speeds which is helpful when roughing and precision work. This also allows for outboard turning up to a 16” bowl on a mid-sized lathe. Electrical Requirements: 110V-1PH-60Hz Recommended Breaker Size: 110V – 15 Amp Speed Range High: 650 – 3500 RPM Speed Range Mid: 325 – 1750 RPM Speed Range Low: 50 – 525 RPM Distance Between Centers: 15-1/2in. Swing Over Bed: 12-1/2in. Swing Over Banjo: 9-1/2in. Max Outboard Swing: 16in. Spindle Bore: 3/8in. Spindle Thread: 1in. x 8 TPI (Both Ends) Front Bearing: 6006LLU Rear Bearing: 6005LLU Indexing: 24 Positions With Lock Accepts Vacuum Chuck: No Drive Belt: Poly-V Belt 6 Grooves Tailstock Quill: MT #2 Tail Stock Quill Travel: 2-1/2in. Bed Length: 29.4in. Bed Gap: 1-1/4in. Tool Rest Length: 6in. Tool Rest Post Diameter: 1in. Faceplate Diameter: 3in. Certification: CSA C/US 256540 Floor To Bed Height: 6-3/4in. No Pads Floor To Spindle Center: 13in. No Pads Overall Size (L x W X H): 35.8in. x 14.6in. x 20.5in. Net Weight: 118 lbs Shipping Weight: 125 lbs Shipping Dimensions: 37in. x 15in. x 21in.

What's Included

    (1) Machine

Features + Benefits

  • 1 HP DC Permanent Magnet Motor
  • Pulse Width Modulation (PWM) Controller
  • 1HP, 110V Motor
  • 12? Swing Over Bed
  • 16? Between Centers

Key Specs

AttributeSpecification

item#

6009612

Brand

Laguna

Manufacturer's Warranty

2 year limited warranty

Ship Weight

125.0 LB

Distance Between Centers

0 in

Horsepower

0

Max. RPM

3,500
AttributeSpecification

Product Type

Lathe

Volts

110

Amps

8

Phase

Single-phase

Product Weight

118.0000 lb

Dimensions L x W x H (in.)

29.4 x 9.0 x 17.4 in

Reviews

Questions & Answers

Questions

Warranty

Manufacturer's Warranty

2 year limited warranty
