Klutch Deluxe Foot Sheet Metal Shear, 52in.L

The shear cut deck height is 32" above finished floor.

The crate will easy fit in a regular pickup. Getting it out may be a problem at around 1100 lbs.

Yes and actually it will do 22 gauge with a little more effort.

The metal shear does have a backstop. It is adjustable up to 35 inches. To adjust this, loosen the adjustment knobs, slide the angle, move the rod forward or backward so the scales read zero on the pointers. Then, lock the bracket again and perform further adjustments with the wheel.

The cutting capacity is not determined by the length and width of the piece. The cutting capacity is determined by the material and thickness of the piece. This shear is capable of cutting 14-ga. aluminum up to 2mm thick, 16-ga. mild steel up to 1.4mm thick, 18-ga. high-carbon steel up to 1.2mm thick, and 30-ga. stainless steel up to 0.3mm thick.

Instructions for making different adjustments to this shear can be found on pages 4 - 6 in the Product Manual which is located below the Product Summary on the web page.

This shear is equipped with a micro adjusting stop assembly.

We have a PDF manual that is listed online just under the Product Summary. Parts for this product are not available directly through Northern Tool + Equipment. Parts for this may be available through our sister company, Jacks Small Engines. Please visit www.JacksSmallEngines.com. To obtain the part numbers you need, please first contact our Parts Department at 1-800-657-0516.

This shear cannot cut 16 gauge stainless steel. It has a maximum capacity of 30 gauge for stainless steel.

This metal shear can cut aluminum up to 2 mm thick, but it is not designed for cutting any plastic. The capacity is not large enough to cut 3 mm and 6 mm Signabond.
