Klutch Air Compressor Filter–Regulator Combo, 1/4in. NPT, 20 CFM

Item# 48521
"Klutch Air Compressor Filter–Regulator Combo, 1/4in. NPT, 20 CFM"
Klutch Air Compressor Filter–Regulator Combo, 1/4in. NPT, 20 CFM

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

Klutch Air Compressor Filter–Regulator Combo, 1/4in. NPT, 20 CFM

Click or Tap image to Zoom

$69.99

  • Shipping:

    Free shipping (lower 48 states) - Available now
    $19.99 Same Day

  • Store Pickup:

    2 in stock at Fredericksburg VA - Pickup in under 1 hr

  • 1/4in. NPT air inlet
  • 20 CFM
  • 145 max. PSI
  • 1-piece design saves space
  • 40-micron sintered bronze filter element can be cleaned and never needs to be replaced

  • Prop 65 Warning: See Details

See full description

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Warranty

  • Compare

Product Summary

Klutch Air Compressor Filter–Regulator Combo features a 1-piece space-saving design. The 40-micron sintered bronze filter element can be cleaned and never needs to be replaced. Aluminum body. Polycarbonate bowl is protected from breakage by steel bowl guard. Red Band alert indicates regulator in unlocked position. Semiautomatic nighttime drain ensures filter is drained when compressor is shut down. Includes mechanical air pressure gauge and mounting bracket.

What's Included

    (1) Air compressor filter–regulator combo (1) Air pressure gauge (1) Wall-mounting bracket

Features + Benefits

  • 1/4in. NPT air inlet
  • 20 CFM
  • 145 max. PSI
  • 1-piece design saves space
  • 40-micron sintered bronze filter element can be cleaned and never needs to be replaced
  • Aluminum body
  • Steel bowl guard protects polycarbonate bowl from accidental breakage
  • Red Band alert indicates regulator in unlocked position
  • Semiautomatic nighttime drain automatically drains filter when line pressure falls below 11 PSI
  • Wall-mounting bracket for easy installation
  • 0.03-oz. bowl capacity

Key Specs

AttributeSpecification

item#

48521

Brand

Klutch

Manufacturer's Warranty

1 year limited warranty

Ship Weight

0.98 LB

CFM

20 cfm
AttributeSpecification

Inlet Diameter

0.25 in

Outlet Diameter

0.25 in

Material

Polycarbonate

Recommended Use

Filter and Regulator

Max. PSI

145

Reviews

Questions & Answers

13 Reviews This action will navigate to reviews.

Questions

1–9 of 9 Questions
Sort by:

  1. minimum psi

    1 answer

    1. The filter regulator will have a pressure adjustment range from 7-145 PSI.

      Helpful?

  2. Where is it made?

    1 answer

    1. This filter-regulator is manufactured to our specifications in India.

      Helpful?

  3. Should this product be mounted a minimum distance from the air compressor for maximum performance or can it be mounted directly on the air compressor?

    1 answer

    1. This can be mounted at any distance, but to filter out the most moisture, you should install this further away from the air compressor, about 20 feet is optimal for this.

      Helpful?

  4. Does this product attach to a 1/4" male coupler or a 1/4" female coupler?

    1 answer

    1. This model is equipped with 1/4" female fittings.

      Helpful?

  5. Will this filter work for paint guns??

    1 answer

    1. The filter/regulator can be used with an air compressor for paint guns.

      Helpful?

  6. Can the airflow direction be changed to be right to left?

    1 answer

    1. The airflow direction cannot be changed.

      Helpful?

  7. Filter Oil?

    Assuming this filters water, does it filter oil from the line of an oil-based pump?

    1 answer

    1. This air filter-regulator combo will remove contaminants including water and oil.

      Helpful?

  8. what are the dimensions and operating temperature ranges of this product?

    1 answer

    1. The dimensions of the filter-regulator combo are 6-9/16" Height by 1-1/2" Width. The ambient operating temperature range is from 32 to 140 degrees Fahrenheit.

      Helpful?

  9. What is the airflow direction?

    It the inlet on the right and outlet on the left?

    1 answer

    1. The inlet would be on the left and outlet would be on the right as you face the gauge.

      Helpful?

Warranty

Manufacturer's Warranty

1 year limited warranty
