Klutch Air Compressor Filter, 1/4in., 28 CFM

Item# 48574
Klutch Air Compressor Filter, 1/4in., 28 CFM

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

Klutch Air Compressor Filter, 1/4in., 28 CFM

Click or Tap image to Zoom

$9.99

  • Shipping:

    Available now
    $19.99 Same Day

  • Store Pickup:

    1 in stock at Fredericksburg VA - Pickup in under 1 hr

  • 1/4in. NPT air inlet
  • 40-micron sintered bronze filter element can be cleaned and never needs to be replaced
  • Aluminum die-cast body
  • Polycarbonate bowl is protected from accidental breakage by steel bowl guard
  • 145 max. PSI

  • Prop 65 Warning: See Details

See full description

Complete Your Solution

  • Klutch Air Compressor Filter, 1/4in., 28 CFM
  • 3M Virtua Protective Safety Glasses, Clear Lens, Model# 11228-00000-100
Price for all two:

$11.98

Frequently Bought Together

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Accessories

  • Warranty

  • Compare

Product Summary

The Klutch Air Compressor Filter features modular construction for easy maintenance. Features a 40-micron sintered bronze filter element can be cleaned and never needs to be replaced. Polycarbonate bowl is protected from breakage by steel bowl guard. 145 max. PSI. Semiautomatic nighttime drain ensures filter is drained when compressor is shut down, eliminating the need to manually drain the collected water.

What's Included

    (1) Air compressor filter

Features + Benefits

  • 1/4in. NPT air inlet
  • 40-micron sintered bronze filter element can be cleaned and never needs to be replaced
  • Aluminum die-cast body
  • Polycarbonate bowl is protected from accidental breakage by steel bowl guard
  • 145 max. PSI
  • Semiautomatic nighttime drain ensures filter is drained when compressor is shut down

Key Specs

AttributeSpecification

item#

48574

Brand

Klutch

Manufacturer's Warranty

1 year limited warranty

Ship Weight

0.5 LB

CFM

28 cfm
AttributeSpecification

Inlet Diameter

0.25 in

Outlet Diameter

0.25 in

Material

Polycarbonate

Recommended Use

Filter

Max. PSI

145

Reviews

Questions & Answers

6 Reviews This action will navigate to reviews.

Questions

1–8 of 8 Questions
Sort by:

  1. How do you clean this air filter?

    1. Disassemble, clean w/soapy water, rinse & let it air dry.

      Helpful?

    2. There are no cleaning instructions available on how to clean the actual filter section. It is recommended to clean the air filter bowl with soap and warm water.

      Helpful?

  2. Do you have any manuals on how to service and clean Klutch water separator?

    1 answer

    1. Before dismantling the unit, exhaust the air in the line completely.

      To clean the filter element and bowl, unscrew the threaded bowl guard by turning it counterclockwise. Disassemble the components and clean the filter element by blowing it out with compressed air. Clean the bowl using soap and water or a neutral detergent.

      Lift the bowl guard upward and pull down the locking piece. Turn the bowl guard 45° and pull it down to remove it.

      Inspect the O-rings and other parts for damage. Replace any damaged components if necessary, or clean and reuse them if they are in good condition.

      Apply general-purpose grease to the O-rings and to the surface of the housing where the O-ring seats. Reassemble all components.

      Screw the threaded bowl guard on to the housing. Position the top flange lug portion of the bowl guard to the corresponding slots in the housing. Push the bowl guard fully into the housing. Turn the bowl guard by 45° until the locking piece enters into the housing slot fully.

      Helpful?

  3. I notice that there is threads in the bottom of the drain valve, is there a way to add a piece of tubing to the drain?

    1 answer

    1. The drain bottom has an M5 thread. A tube can be attached as long as it matches the thread.

      Helpful?

  4. Does this filter have to be level? I have a Makita 2 Gallon quiet compressor and the outlet is at an angle, maybe 30 degrees. Thanks

    1 answer

    1. This filter should be mounted level, not at an angle.

      Helpful?

  5. I am putting this filter on a pancake compressor that is mounted on a bracket on a wall Please advise on the semi automatic draining feature. When the compressor is turned off is the drain feature going to drain water on to the floor?

    1 answer

    1. The semi-auto drain is similar to a check valve; it is closed when pressure is applied and opens when pressure is removed. The drain automatically opens when the liquid in the bowl reaches a certain level. You would open the drain valve to remove the water, place a pan below the valve to catch the water to avoid it draining onto the floor.

      Helpful?

  6. Are model specific mouting brackets available for this filter?

    1 answer

    1. There are no mounting brackets available for this air filter.

      Helpful?

  7. What material is the drain valve made of and does it have any seals in it?

    1 answer

    1. This air filter has a drain valve that is made of plastic. The drain valve threads onto a metal fitting with a plastic washer and a rubber seal in between them.

      Helpful?

  8. How do you install this filter?

    1 answer

    1. This air filter attaches to the outlet port on your compressor. This filter has both 1/4" NPT female inlet and outlet ports. The air hose then attaches to the outlet port on the filter.
