King Kutter XB Rotary Kutter, 48in., Model# L-48-40-XB

Item# 256007
King Kutter XB Rotary Kutter, 48in., Model# L-48-40-XB

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

King Kutter XB Rotary Kutter, 48in., Model# L-48-40-XB

Click or Tap image to Zoom

$1738.99

  • Shipping:

    Factory shipped

    Heavy/large item. Lift gate service available.

  • Store Pickup:

    Not available - online only
  • Rugged steel side rails and 1-pc. fully reinforced top deck
  • Adjustable tail wheels
  • Heavy-duty cast iron gearbox
  • Shielded PTO shaft with shear pin
  • Heavy stump jumper with forged, heat-treated blades

See full description

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Accessories

  • Warranty

  • Compare

Product Summary

KING KUTTER'S XB ROTARY KUTTER is a quality constructed durable Kutter that is built to last. It is constructed with rugged steel side rails and has one-piece top deck that is fully reinforced. Standard features include a cast iron gearbox, stump jumper, twin tail wheels and a shielded PTO shaft with a shear pin. Truck ship. U.S.A.

What's Included

    (1) King Kutter XB rotary kutter

Downloads

Product Manual

Features + Benefits

  • Rugged steel side rails and 1-pc. fully reinforced top deck
  • Adjustable tail wheels
  • Heavy-duty cast iron gearbox
  • Shielded PTO shaft with shear pin
  • Heavy stump jumper with forged, heat-treated blades
  • Top link swivel
  • Rubber shielding standard
  • 18in.L x 3in.W x 1/2in. Thick blade

Key Specs

AttributeSpecification

item#

256007

Brand

King Kutter

Manufacturer's Warranty

1 year limited warranty

Ship Weight

401.0 LB

Product Type

Rotary Mower

Category

Category 1

Working Width

48 in
AttributeSpecification

RPM

540

Hitch Type

3-Point

Blades (qty.)

2

Min. Horsepower

18

Max. Horsepower

25

Min. Cutting Height

4 in

Max. Cutting Height

8 in

Reviews

Questions & Answers

1 Review This action will navigate to reviews.

Questions

1–9 of 9 Questions
Sort by:

  1. how much horsepower does the king cutter model #l-48-40-xb require

    1. I've used a 48inch rotary cuttery on a subcompact 24hp New Holland tractor (tractor fits into the back of a pickup) The cutter worked very well. The only issue is that we needed to add some balast to the front of the tractor.

      Helpful?

    2. The rotary cutter is for a category 1 tractor which would fit on up to a 45 HP tractor. It does require 540 RPM on the PTO to engage the mower.

      Helpful?

  2. Does this have a standard PTO Spline and 3 Point Hitch attachment?

    1 answer

    1. The PTO shaft will be a 1 3/8" x 6 spline. The rotary kutter will work with a category one pin size.

      Helpful?

  3. What type of oil goes in the gearbox?

    1 answer

    1. Fill the gearbox using a multi purpose gear oil (SAE 80W/90 or SAE 85W140). For the grease fittings use a type grade II tube grease.

      Helpful?

  4. What guage metal is the mower deck made of, and how many blades does it use?

    1 answer

    1. The deck is made of 12-gauge metal and this mower uses two blades.

      Helpful?

  5. DIAMETER OF BRUSH IT WILL CUT?

    JUST WONDERING THE DIAMETER OF BRUSH, SMALL SAPLING/TREES THIS WILL CUT.

    1 answer

    1. This King Kutter XB Rotary Kutter can cut brush and saplings with diameters up to 3/4".

      Helpful?

  6. Are these solid rubber tires?

    1 answer

    1. The two tires on this rotary cutter are made of solid rubber.

      Helpful?

  7. Blade Access

    Is there a hole in the deck that allows you access to the blade bolt nut through the top of the deck?

    1 answer

    1. This unit features a hole in the deck that allows you access to the blade bolt nut through the top of the deck.

      Helpful?

  8. Rear Wheels

    Can the rear wheel supports be adjusted to change the height of the rear of the mower?

    1 answer

    1. This mower does come with adjustable rear wheels as well as spacers to adjust your cutting range from approximately two inches to six inches in height.

      Helpful?

  9. Blade Height

    How low will this unit mow grass?

    1 answer

    1. The cutting heights on this mower range from approximately two inches to six inches.

      Helpful?

Warranty

Manufacturer's Warranty

1 year limited warranty
