K & M, KM 132 UNI PRO, Model# 8280

Item# 47818
K & M, KM 132 UNI PRO, Model# 8280

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

K & M, KM 132 UNI PRO, Model# 8280

Click or Tap image to Zoom

$164.99

  • Shipping:

    Factory shipped

  • Store Pickup:

    Not available - online only
  • Blow molded plastic frame
  • Ergonomic cushion
  • Vacuum-formed waterproof vinyl
  • Central drain hole prevents water build up
  • 15 1/2in. high-back seat which will replace both original 15 1/2in. and 18 3/4in. high-back seats

See full description

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Accessories

  • Warranty

  • Compare

Product Summary

The KM 132 Uni Pro Hinged Bucket Seat is a comfortable, quality-made seat suitable for agricultural tractors and turf applications. It is designed for use with hinged panned 15 1/2in. and 18 3/4in. tall backrest seats. The seat is a drop in replacement, simply remove the existing seat by removing the pin, remove the seat switch and install the new seat and seat switch.

What's Included

    (1) Seat

Downloads

Product Manual Product Manual2

Features + Benefits

  • Blow molded plastic frame
  • Ergonomic cushion
  • Vacuum-formed waterproof vinyl
  • Central drain hole prevents water build up
  • 15 1/2in. high-back seat which will replace both original 15 1/2in. and 18 3/4in. high-back seats
  • 9.17in. inside bracket measurement
  • Accepts operator presence switch
  • Yellow vinyl

Key Specs

AttributeSpecification

item#

47818

Brand

Uni Pro

Manufacturer's Warranty

12 months parts/12months labor

Ship Weight

11.0 LB

Adjustable

No
AttributeSpecification

Suspension

No

Color

Yellow

Material

Vinyl

Arm Rests

No

Universal Fit

No

Reviews

Questions & Answers

32 Reviews This action will navigate to reviews.

Questions

1–6 of 6 Questions
Sort by:

  1. What is the measurement between the hinges.

    Will this seat replace the Scotts seat on the Riding Mower.

    1. only about 9inches

      Helpful?

    2. The dimension on the "K & M Uni Pro Hinged Bucket Seat - Yellow, Model# 8280, between the hinges is 9" from inside to inside of the hinge. The measurement from outside to outside of the hinge is 11". It is designed for use with hinged panned 15 1/2in. and 18 3/4in. tall backrest seats as a drop in replacement. If your seat meets these dimensions it will work.

      Helpful?

  2. Will this replace the John Deere 2320 seat?

    1 answer

    1. This seat would not work for a replacement for the John Deere 2320 seat.

      Helpful?

  3. Measurements on the inside dimension and outside dimension of where it hatches ?

    1 answer

    1. The dimension between the hinges is 9" from inside to inside of the hinge. The measurement from outside to outside of the hinge is 11".

      Helpful?

  4. Does this fit a JD GX 325

    1 answer

    1. Yes, this seat is compatible with the John Deere GX 325.

      Helpful?

  5. Hinge width?

    Is the hinge only 1" wide? I have a Gator CX and the inside measurement is 9", but the outside measurement is about 12 1/2".

    1 answer

    1. The hinge on each side is 1" wide.

      Helpful?

  6. Hole Dia.

    What diameter hole for the hinge pin is in this seat/K& M Uni Pro Hinged Bucket Seat-Yellow, Model #8280 ?

    1 answer

    1. The diameter hole for the hinge pin is .386 inches.

      Helpful?

Warranty

Manufacturer's Warranty

12 months parts/12months labor
