JET Variable Speed Geared Head Square Column Mill/Drill, 1 1/2 HP, 115/230V, Model# JMD-45VSPF

Item# 66124
JET Variable Speed Geared Head Square Column Mill/Drill, 1 1/2 HP, 115/230V, Model# JMD-45VSPF

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

JET Variable Speed Geared Head Square Column Mill/Drill, 1 1/2 HP, 115/230V, Model# JMD-45VSPF

Click or Tap image to Zoom

$8697.99

  • Shipping:

    Free shipping (lower 48 states) - Factory shipped

    Heavy/large item. Lift gate service available.

  • Store Pickup:

    Not available - online only
  • Square column with dovetail ways
  • Full power to the cutting tools through a variable speed geared head
  • Power downfeed is standard
  • Head tilts left and right 90º for added versatility
  • Rapid spindle speed changes through quick-select gear shift levers

  • Prop 65 Warning: See Details

See full description

Complete Your Solution

  • JET Variable Speed Geared Head Square Column Mill/Drill, 1 1/2 HP, 115/230V, Model# JMD-45VSPF
  • Milwaukee Men's Cut 1 Nitrile Utility Gloves, Red/Black, Large, Model# 48-22-8902
  • 3M SecureFit Safety Glasses, Clear Lens, Model# SF400C-LV-4-PS
  • Radians Earplug Neckband, NRR 25dB, Orange, Model# RB2120
Price for all four:

$8721.44

Frequently Bought Together

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Accessories

  • Warranty

  • Compare

Product Summary

This heavy-duty JET Variable Speed Geared Head Square Column Mill/Drill with 1 1/2 HP motor is engineered to deliver the rigidity needed to perform a variety of precision drilling applications in high intensity environments. CSA/CUS certified. Please closely verify all details prior to confirming this order. NOTE: Because this made-to-order item is manufactured exclusively to match your specifications, it is not eligible for cancellation, refund or return once the order has been placed.

What's Included

    (1) Variable speed geared head square column mill/drill

Downloads

Product Manual

Features + Benefits

  • Square column with dovetail ways
  • Full power to the cutting tools through a variable speed geared head
  • Power downfeed is standard
  • Head tilts left and right 90º for added versatility
  • Rapid spindle speed changes through quick-select gear shift levers
  • Calibrated fine down feed is built in
  • Easy-to-read internal depth gauge
  • Forward/reverse switch
  • Spindle guard
  • Work lamp for better visibility during operation
  • Milling table allows for movement
  • R8 spindle design allows for the use of all mill tooling
  • 115/230 dual voltage operation

Key Specs

AttributeSpecification

item#

66124

Brand

JET

Manufacturer's Warranty

24 months parts/24months labor

Ship Weight

827.0 LB

Horsepower

1.5 HP

Volts

115/230

Max. Speed

2,500 rpm

360 Degree Head Swivel

No

Product Type

Milling Machine/Drill Press
AttributeSpecification

Vertical Stroke

4-1/4 in

Drilling Capacity

1-1/2 in

Light Included

Yes

Stand Included

No

Variable Speed

Yes

Max. Spindle Distance

18.125 in

Swing

19.687 in

Product Weight

827.0000 lb

Dimensions L x W x H (in.)

29.0 x 36.0 x 50.0 in
