JET PT Series Heavy-Duty Manual Trolley, 10-Ton Capacity, Fits 4 3/4in.W-8in.W Beams, Model# 10-PT

Item# 65104
JET PT Series Heavy-Duty Manual Trolley, 10-Ton Capacity, Fits 4 3/4in.W-8in.W Beams, Model# 10-PT

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

JET PT Series Heavy-Duty Manual Trolley, 10-Ton Capacity, Fits 4 3/4in.W-8in.W Beams, Model# 10-PT

Click or Tap image to Zoom

$1601.99

  • Shipping:

    Free shipping (lower 48 states) - Factory shipped

    Heavy/large item. Lift gate service available.

  • Store Pickup:

    Not available - online only
  • Heavy-gauge steel for durability
  • Large, hardened steel wheels and thick bearings for smooth movement on a variety of beams
  • Built-in bumper guards for user safety and long trolley life
  • Adjusts easily to wide-flange H-beams, standard I-beams or curved track
  • Powder-coat finish for corrosion resistance

  • Prop 65 Warning: See Details

See full description

Complete Your Solution

  • JET PT Series Heavy-Duty Manual Trolley, 10-Ton Capacity, Fits 4 3/4in.W-8in.W Beams, Model# 10-PT
  • JET S90 Series Manual Chain Hoist, 5-Ton Capacity, 20ft. Lift, Model# S90-500-20
Price for all two:

$2651.98

Frequently Bought Together

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Accessories

  • Warranty

  • Compare

Product Summary

The JET PT Series Heavy-Duty Manual Trolley features heavy-gauge steel for durability. Large, hardened steel wheels and thick bearings move smoothly on a variety of beams. Built-in bumper guards increase user safety and extend trolley life. This unit can be easily adjusted to wide-flange H-beams, standard I-beams or curved track with the included spacer washers. Powder-coat finish protects against corrosion. Compliant with OSHA and ANSI/ASME B30.11 and B30.17 standards. Load tested to 125% of capacity with certificate.

What's Included

    (1) Trolley

Features + Benefits

  • Heavy-gauge steel for durability
  • Large, hardened steel wheels and thick bearings for smooth movement on a variety of beams
  • Built-in bumper guards for user safety and long trolley life
  • Adjusts easily to wide-flange H-beams, standard I-beams or curved track
  • Powder-coat finish for corrosion resistance
  • Includes spacer washers
  • Compliant with OSHA and ANSI/ASME B30.11 and B30.17 standards
  • Load tested to 125% of capacity with certificate

Key Specs

AttributeSpecification

item#

65104

Brand

JET

Manufacturer's Warranty

24 months parts/24months labor

Ship Weight

211.0 LB

Style

Manual Trolley

Capacity

20,000 lb

Adjustable

Yes
AttributeSpecification

Max. Beam Height

24.5 in

Min. Flange Width

4.75 in

Max. Flange Width

8 in

Min. Radius Curve

67 in

OSHA Approved

Yes

Product Weight

lb

Dimensions L x W x H (in.)

20.0 x 11.5 x 15.5 in

Reviews

Questions & Answers

Questions

  1. What are the dimensions of an individual wheel? Diameter and flange length that kicks out on the I-beam?

    1 answer

    1. The wheel diameter is 6", the width of the portion that comes in contact with the beam is 1.25" W.

      Helpful?

Accessories We Recommend

This is a carousel with auto-rotating slides. Activate any of the buttons to disable rotation. Use Next and Previous buttons to navigate, or jump to a slide with the slide dots.

Warranty

Manufacturer's Warranty

24 months parts/24months labor
