Ironton Y-Style Side-Mount Utility Truck Rack, 250-Lb. Capacity, Steel

Item# 48113
Top Seller
Ironton Y-Style Side-Mount Utility Truck Rack, 250-Lb. Capacity, Steel

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

Ironton Y-Style Side-Mount Utility Truck Rack, 250-Lb. Capacity, Steel

Click or Tap image to Zoom

$124.99

  • Shipping:

    Free shipping (lower 48 states) - Available now
    $19.99 Same Day

  • Store Pickup:

    2 in stock at Fredericksburg VA - Pickup in under 1 hr

  • Y-style side-mount rack frees up your truck bed
  • 250-lb. load capacity
  • Bolt-on base securely mounts each rack to cargo bed (drill mount required for secure installation)
  • Fits most makes and models of trucks
  • Can be mounted on either side of truck

  • Prop 65 Warning: See Details

See full description

Complete Your Solution

  • Ironton Y-Style Side-Mount Utility Truck Rack, 250-Lb. Capacity, Steel
  • Buyers Products, 1.5in. Ratchet Tie Down Square Rectangular Tube Ladder Racks, Working Load 500 lb, Straps (qty.) 2 Breaking Strength 1500 lb, Model# 5480005
  • Keeper Rack-Ratchet Tie-Down System, 1-1/2in. x 8ft., Model# 05530
  • Forester Indoor/Outdoor Safety Glasses 4-Pack, 3 Pairs with Clear Lens, 1 Pair with Tinted Lens, Model# GLA-4
Price for all four:

$264.96

Frequently Bought Together

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Accessories

  • Warranty

  • Compare

Product Summary

The Ironton Y-Style Side-Mount Rack lets you free up your truck bed by storing longer cargo on the stand. Supports extension ladders, deck boards, PVC pipes, canoes and more. Can handle up to 250 lbs.

What's Included

    (1) Y-style side-mount utility truck rack (1) Hardware bag

Downloads

Product Manual
Play Item Video

Features + Benefits

  • Y-style side-mount rack frees up your truck bed
  • 250-lb. load capacity
  • Bolt-on base securely mounts each rack to cargo bed (drill mount required for secure installation)
  • Fits most makes and models of trucks
  • Can be mounted on either side of truck
  • Telescoping support arms adjust from 19in.–32in. and 0°–20° tilt
  • Rack can be easily removed
  • Rugged steel construction with black powder-coat finish
  • 39in.L x 7in.W x 51-3/16in.H

Key Specs

AttributeSpecification

item#

48113

Brand

Ironton

Manufacturer's Warranty

1 year limited warranty

Ship Weight

49.0 LB

Load Capacity

250 lb

Material

Steel
AttributeSpecification

Finish

Powder-Coat

Mounting Hardware Included

Yes

No-Drill Clamps

No

Product Weight

lb

Dimensions L x W x H (in.)

39.0 x 7.0 x 51.18 in

Reviews

Questions & Answers

16 Reviews This action will navigate to reviews.

Questions

1–9 of 9 Questions
Sort by:

  1. Can this be installed on a flat bed?

    1 answer

    1. The mounting brackets are not flat, so they would not mount properly on a flat bed.

      Helpful?

  2. Do I have to drill holes in my truck for installation?

    1 answer

    1. Holes will need to be drilled into the truck for installation.

      Helpful?

  3. Can these be installed in the stake pockets?

    1 answer

    1. The front upright support bracket will be bolted to the front bulkhead with one bolt on each side of the upright section and one bolt in the side stake pocket of the truck bed. The rear upright support bracket will be bolted to the vertical inside or forward face of the inner bed wall around the rear stake pocket. Complete installation instructions are found in the product manual beginning on page 7.

      Helpful?

  4. If the upper arms are removed are all other parts below the cab? I want to make certain I am able to go through a car wash.

    1 answer

    1. It would be recommended to remove the upper arms prior to a car wash. The truck rack may be damaged in a car wash.

      Helpful?

  5. Is the bolt-on hardware supplied with this rack?

    1 answer

    1. Hardware is supplied with this unit. The list of hardware can be referenced on page 11 of the product manual. The manual can be located under the What's included portion of the item's web page in the red underlined PDF form.

      Helpful?

  6. Are the top parts of this ladder rack removable when you dont need them or do you have to unbolt the whole thing?

    1 answer

    1. The upper arms and brackets of this ladder rack can be removed without unbolting the front and rear upright support brackets from the vehicle.

      Helpful?

  7. What is the size of the square tube?

    1 answer

    1. There are multiple size squared tubing sections associated with item. The sizes are as follows: The 2 horizontal cross arms measure 1-1/2" squared. The smaller squared tubing on the 2 adjustable arms measures 1-1/4" and the larger squared tubing of arms measures 1-1/2". The 2 upright supports measure 1-13/16" squared. The 2 uprights measure 1-1/2" squared. The single rear upright support bracket measures 2" squared and the single front upright support bracket also measures 2" squared.

      Helpful?

  8. Can I use this on the side of a utility trailer?

    1 answer

    1. This utility truck rack is intended to be mounted on a truck, however if it is mounted properly it can be used on a utility trailer.

      Helpful?

  9. What is the height, in inches, of the mount that is bolted to the truck? (From the bottom of the mounting flange to the top of the square tube)

    bolted to the truck? ( from the bottom of the mounting flange to the top of the receiver tube) I want to know if it will fit under my tonneau cover when the upper rack is not attached.

    1 answer

    1. From the mounting flange to the top of the rack is one piece that is 52-13/64" tall. There is a telescoping support arms that adjust from 19in. to 32in. and 0° to 20° tilt. This is not designed to be able to fit under a Tonneau cover.

      Helpful?
