Ironton Linear Actuator, 12 Volt DC, 7-7/8in. Stroke

Item# 74280
"Ironton Linear Actuator, 12 Volt DC, 7-7/8in. Stroke"
Ironton Linear Actuator, 12 Volt DC, 7-7/8in. Stroke

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

Ironton Linear Actuator, 12 Volt DC, 7-7/8in. Stroke

Click or Tap image to Zoom

$189.99

  • Shipping:

    Free shipping (lower 48 states) - Available now

  • Store Pickup:

    Not available - online only
  • 7-7/8in. stroke
  • 4mm per second travel speed (no load)
  • 660 lbs. rated load thrust
  • 1,300-lb. max. static load capacity (1,100-lb. dynamic load capacity)
  • Center-to-center closed pin distance is 13-3/8in. (340mm)

See full description

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Warranty

  • Compare

Product Summary

This Ironton Linear Actuator is perfect for raising and lowering lawn and garden tractor and ATV attachments, along with hoods, trunks, tonneau covers, tailgates, truck covers and more. The actuator pushes and pulls with equal force for consistently smooth and effective operation. An integrated travel limit switch prevents over extension.

What's Included

    (1) Ironton Linear Actuator

Downloads

Product Manual

Features + Benefits

  • 7-7/8in. stroke
  • 4mm per second travel speed (no load)
  • 660 lbs. rated load thrust
  • 1,300-lb. max. static load capacity (1,100-lb. dynamic load capacity)
  • Center-to-center closed pin distance is 13-3/8in. (340mm)
  • Integrated travel limit switch prevents over extension
  • Locks in place if power is lost
  • 13.39in.L retracted; 21.26in.L extended
  • Rugged metal gears

Key Specs

AttributeSpecification

item#

74280

Brand

Ironton

Manufacturer's Warranty

1 year limited warranty

Ship Weight

5.32 LB

Stroke Length

7.87 in

Dynamic Load Capacity

1,100 lb

Static Load Capacity

1,300 lb
AttributeSpecification

Product Type

Linear Actuator

Gear Ratio

37:1

Length Retracted

13.4 in

Length Extended

21.25 in

Volts

12

Frame Material

Aluminum

Product Weight

5.42 lb

Reviews

Questions & Answers

11 Reviews This action will navigate to reviews.

Questions

1–10 of 12 Questions
Sort by:

  1. Is this actuator waterproof or water resistant?

    1 answer

    1. The linear actuator is not water or weather proof.

      Helpful?

  2. Does this actuator have force both directions stop and reverse direction anywhere?

    1 answer

    1. The actuator pushes and pulls with equal force.

      Helpful?

  3. Is this outdoor rated, does it meet an ip rating?

    1 answer

    1. This is ideal for raising and lowering lawn and garden equipment, tractors,
      ATV attachments, tailgates, truck covers, and more. This has a temperature range of 41 to 104 degrees F. This does not have an IP rating.

      Helpful?

  4. What is the diameter of the bolt holes in acuator piston

    1 answer

    1. The diameter of the bolt holes in the actuator piston would be 3/8".

      Helpful?

  5. I'm looking for something to use as a pivot actuator for my ATV plow blade, is this suitable for wet or cold environments? Will it stand up to being loaded by pushing snow?

    1 answer

    1. This should not be used on a snowplow blade. The temperature range for using this is 41 degrees F - 104 degrees F.

      Helpful?

  6. Does it come with controls?

    1 answer

    1. This does not come with a control or switch. This includes wiring that is 22.8" long that can be connected to a 12 volt battery with a switch.

      Helpful?

  7. What is the amp draw of this with a load?

    1 answer

    1. The amperage rating is 10 amps.

      Helpful?

  8. What is the actuation time?

    1 answer

    1. This will have a travel speed of 4mm per second with no load.

      Helpful?

  9. Does the actuator include wiring? Can it be wired into the garden tractor battery with a switch?

    1 answer

    1. This actuator does include wiring that is 22.8" long. This can be connected to a 12V battery with a switch.

      Helpful?

  10. what is the country of origin of this product?

    1 answer

    1. This actuator is manufactured in Taiwan.

      Helpful?

Warranty

Manufacturer's Warranty

1 year limited warranty
