Ingersoll Rand F-Series General 1 Micron Filter, 1/2in., 22 CFM, Model# FA40IG

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

Click or Tap image to Zoom
Shipping:
Free shipping (lower 48 states) - Factory shippedStore Pickup:
Not available - online only
- F-Series filter kit is a general 1 micron compressed air filter to reduce contamination in your air stream
- Ergonomic bowl design with no-touch filter simplifies element replacement
- Proprietary media coating technology protects against corrosion and increases element life
- Works with Item#s 1592071,106547
- 1/2in. inlet, 1/2in. outlet
See full description
Description
Key Specs
Reviews
Q & A
Warranty
Compare
Product Summary
What's Included
- (1) Complete filter assembly
Features + Benefits
- F-Series filter kit is a general 1 micron compressed air filter to reduce contamination in your air stream
- Ergonomic bowl design with no-touch filter simplifies element replacement
- Proprietary media coating technology protects against corrosion and increases element life
- Works with Item#s 1592071,106547
- 1/2in. inlet, 1/2in. outlet
- 22 CFM
- Patented dual indicator shows differential pressure drop and operating efficiency
- Rugged all-aluminum, precision die cast body suitable for 176°F / 80°C and 250 PSIG / 17.2 bar MAWP applications
- Filter element with stainless steel mesh withstands high pressure and minimizes flow restriction for reliable operation
Key Specs
| Attribute | Specification |
|---|---|
item# | 108024 |
Brand | Ingersoll Rand |
Manufacturer's Warranty | 1 year limited warranty |
Ship Weight | 4.0 LB |
CFM | 22 cfm |
Max. Temperature | 176 °F |
Inlet Diameter | 0.5 in |
| Attribute | Specification |
|---|---|
Outlet Diameter | 0.5 in |
Material | Aluminum |
Compatible With | Item#s 1592071, 106547 |
Recommended Use | Filter |
Max. PSI | 246.5 |
Product Weight | 4.0000 lb |
Dimensions L x W x H (in.) | 3.0 x 4.0 x 12.0 in |
Reviews
Questions & Answers
Questions
-
· 3 years ago
How do you mount this to a wall
1 answer-
ProductExpert6· 3 years ago
Helpful?
-
-
· 4 years ago
Does this include the filter?
1 answer-
ProductExpert13· 4 years ago
This will include the filter.
Helpful?
-
Warranty
Manufacturer's Warranty
1 year limited warranty
