Ingersoll Rand Air Angle Die Grinder, 1/4in., Model# 3101G

Item# 1540329
Top Seller
Ingersoll Rand Air Angle Die Grinder, 1/4in., Model# 3101G

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

Ingersoll Rand Air Angle Die Grinder, 1/4in., Model# 3101G

Click or Tap image to Zoom

$74.99

  • Shipping:

    Backordered: Order now to reserve yours -
    Estimated to ship 09/17/26

  • Store Pickup:

    Not Available
  • Ideal for weld grinding, deburring, surface prep and polishing
  • Lightweight, durable composite body
  • 1/3 HP motor
  • Ball bearing construction
  • Contoured ergonomic grip

See full description

Complete Your Solution

  • Ingersoll Rand Air Angle Die Grinder, 1/4in., Model# 3101G
  • Ingersoll Rand Mega Impact Socket Set — 86-Pc., 3/8in. and 1/2in. Drives, SAE and Metric, Model# SK34C86N
  • Ingersoll Rand ARO Combination Air System Accessories, 3/8in., Filter, Regulator, Lubricator, 71 CFM, Model# C38231600VS
  • Ingersoll Rand T-30 Select Compressor Oil, 1 Liter Bottle
Price for all four:

$748.96

Frequently Bought Together

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Accessories

  • Warranty

  • Compare

Product Summary

The Ingersoll Rand Air Angle Die Grinder, is a versatile and powerful tool designed for precision tasks such as weld grinding, deburring, surface preparation, and polishing. Engineered to provide superior control, this die grinder excels in accessing hard-to-reach areas, making it an essential addition to any professional's toolkit. Featuring a compact design and ergonomic grip, it ensures comfortable handling and reduces user fatigue during extended use. The 1/4-inch collet allows for compatibility with a wide range of accessories, enhancing its functionality across various applications. Built with durability in mind, the Ingersoll Rand Air Angle Die Grinder combines robust construction with reliable performance, ensuring long-lasting use even in demanding environments. Whether you're working on automotive repairs, metal fabrication, or general maintenance, this air angle die grinder delivers precise results with efficiency and ease.

What's Included

    (1) Air angle die grinder

Features + Benefits

  • Ideal for weld grinding, deburring, surface prep and polishing
  • Lightweight, durable composite body
  • 1/3 HP motor
  • Ball bearing construction
  • Contoured ergonomic grip

Key Specs

AttributeSpecification

item#

1540329

Brand

Ingersoll Rand

Manufacturer's Warranty

12 months parts/12months labor

Ship Weight

1.9 LB

Max. Speed

20,000 rpm

Air Inlet Size

1/4 in
AttributeSpecification

Collet Size

1/4 in

Product Type

Die

Min. Hose Size

3/8 in

Side Handle

No

Air Consumption

3 cfm

Reviews

Questions & Answers

59 Reviews This action will navigate to reviews.

Questions

1–9 of 9 Questions
Sort by:

  1. is this tool reversable?

    1. This tool is not reversable.

      Helpful?

    2. Single direction tool. supply air, throttle is digital, all on or all off.

      Helpful?

    3. No it is not reversible.

      Helpful?

    4. Is not reversable. Only spins to the right.

      Helpful?

    5. This Ingersoll Rand Angle Die Grinder is not reversible.

      Helpful?

  2. How big of a compressor you need?

    If it takes 18cfm at load?

    1. I use the tool with a 60 gallon, 5 hp, two stage compressor, rated at 14.3 CFM, 90 PSI. My air system is set for 110 PSI. There is a slight decrease is power as the tank pressure drops but performance remains very good. I can run the tool continuously and still have good performance.

      Helpful?

    2. To run this tool for hours on end, you would need a min of a 7.5 hp single stage compressor. But most users only use a grinder a short time,stop then continue grinding. With short runs with stopping ,you can get by with a 5hp 2 stage compressor. This what I run and have no problems.

      Helpful?

    3. I use it with a 60 gallon/5HP model and it works just fine. Even continuous on, it will kick on and off every minute or so.

      Helpful?

    4. Listed below are some options that would provide the necessary requirements to run this grinder.

      Helpful?

  3. Is this grinder made in the USA?

    1. This Ingersoll Rand Angle Die Grinder is made in China.

      Helpful?

    2. no.

      Helpful?

    3. This Ingersoll Rand Angle Die Grinder in not made in the USA, it is made in China.

      Helpful?

  4. What is maximum air pressure and what is maximum rpm ?

    1 answer

    1. The maximum air pressure recommended for this die grinder is 90 PSI. It would have a maximum rating of 20,000 RPM.

      Helpful?

  5. How do you grease the 3101 g air angle die grinder Ingersoll Rand?

    1 answer

    1. This angle die grinder can be greased with a grease gun through the fitting at the base of the die grinder head. Full instructions can be found in the manual that is included with the die grinder.

      Helpful?

  6. Does the air exhaust come out the back or front?

    1 answer

    1. The angle die grinder will come with rear exhaust. The exhaust will come out near the air inlet.

      Helpful?

  7. Is this grinder variable speed?

    1 answer

    1. The die grinder does not have a variable speed controller.

      Helpful?

  8. Does it come with wrenches for the collet?

    1 answer

    1. Yes, this unit is packaged with a set of wrenches.

      Helpful?

  9. are the mating gears in the head steel or plastic

    If there steel this grinder is a great deal. If plastic i would not purchase.

    1 answer

    1. The Ingersoll Rand Angle Die Grinder does feature steel gears.

      Helpful?
