Industrial Gold Gas-Powered Compressor/Generator/Welder, 14 HP CRX Engine, 30-Gallon Horizontal Tank, Model# CI13GEX33-GW

Item# 114732
Industrial Gold Gas-Powered Compressor/Generator/Welder, 14 HP CRX Engine, 30-Gallon Horizontal Tank, Model# CI13GEX33-GW

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

Industrial Gold Gas-Powered Compressor/Generator/Welder, 14 HP CRX Engine, 30-Gallon Horizontal Tank, Model# CI13GEX33-GW

Click or Tap image to Zoom

$3719.00

  • Shipping:

    Factory shipped

    Heavy/large item. Lift gate service available.

  • Store Pickup:

    Not available - online only
  • Large bore, cast-iron, industrial-grade compressor pump allows for lower vibration and operating temperatures
  • Heavy-duty generator/welder head
  • 240 Amp welder
  • 5000 Watt generator
  • 14 HP CRX engine

See full description

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Warranty

  • Compare

Product Summary

The all-in-one Industrial Gold Gas-Powered Compressor/Generator/Welder gives you more for less. The 16.5 CFM air compressor allows you to operate up to a 3/4in. impact wrench or grinders and cut-off wheels, while the 5000 Watt generator keeps electrical equipment on your jobsite running all day long. The 240 Amp welder gives you the ability to tackle all kinds of welding jobs, large or small.

What's Included

    (1) 14 HP compressor/generator/welder

Downloads

Product Manual Product Manual2
Play Item Video

Features + Benefits

  • Large bore, cast-iron, industrial-grade compressor pump allows for lower vibration and operating temperatures
  • Heavy-duty generator/welder head
  • 240 Amp welder
  • 5000 Watt generator
  • 14 HP CRX engine
  • 16.5 CFM at 175 PSI
  • Flexible stainless steel compressor pump discharge air line
  • Built-in vibration resonance dampeners on drive engine
  • Built-in compressor belt tensioning
  • Built-in generator/welder belt tensioning
  • 2-pc. compressor tank and top plate system
  • Critical compressor controls protected by compressor tank and top plate
  • Full saddle compressor tank feet
  • Compressor controls protected by compressor top plate

Key Specs

AttributeSpecification

item#

114732

Brand

Industrial Gold

Manufacturer's Warranty

12 months parts/12months labor

Ship Weight

700.0 LB

Horsepower

14 HP

Air Tank Size

30 Gal

Engine Brand

CRX

CFM at 90 PSI

21

Max. PSI

200

Stage

2

Amps

240

Duty Cycle

70 %

Fuel Capacity

0.25 Gal
AttributeSpecification

Working Pressure

175 PSI

Engine Displacement

420 cc

Engine Start Type

Electric and Pull

Pump Life

15,000 hr

Pump Material

Cast Iron

Air Outlet Size

3/4 in. NPT

CFM at 40 PSI

22

CFM at Max. PSI

21

After Cooler Included

Yes

Tank Orientation

Horizontal

Product Weight

500.0000 lb

Dimensions L x W x H (in.)

48.0 x 24.0 x 50.0 in

Reviews

Questions & Answers

2 Reviews This action will navigate to reviews.

Questions

1–5 of 5 Questions
Sort by:

  1. What CFM at 90 psi? Also, can you weld and use the air compressor at the same time? If so, at what amperage can you weld at?

    1 answer

    1. The air compressor would be rated at 14.3 CFM at 90 PSI. Yes, you can weld and use the air compressor simultaneously. The unit features a 240 Amp DC welder and a 16.5 CFM, two-stage cast iron air compressor powered by a 13 HP Honda engine, allowing for concurrent operation to run tools while welding. The welder offers a maximum output of 240 amps. While it is designed to run both, you should be mindful of the load. The engine provides 5000 Watts of generator power to support electrical tools while the compressor runs, and the welder runs off the same engine.

      Helpful?

  2. Is there a drain on the bottom of the tank

    1 answer

    1. This Industrial Gold Gas-Powered Compressor/Generator/Welder does have a drain at the bottom of the tank called a petcock drain.

      Helpful?

  3. types of outlits, 240,110...

    1 answer

    1. The generator on this welder would have one 41 amp 110 volt outlet and one 20 amp 240 volt outlet.

      Helpful?

  4. Do you have cover for it

    1 answer

    1. We do not offer a cover to fit this generator/welder.

      Helpful?

  5. What all comes with this set up?

    1 answer

    1. The package will arrive as shown in the image. The compressor, generator, welder and battery will be included. Air hose, electrical cords, and welding components would not be included.

      Helpful?

Warranty

Manufacturer's Warranty

12 months parts/12months labor
