This engine is rated at approximately 4.8 HP.
Honda Engines, HONDA 160CC OHV ENGINE, Engine Displacement 163 cc, Engine Type GX Series OHV Commercial-duty, Shaft Diameter 3/4 in, Model# GX160UT2XQC9
This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.
Click or Tap image to Zoom
$599.99
- Honda 163cc GX OHV air-cooled, 4-stroke, horizontal engine
- Automatic decompression for easy starting
- Heavy-duty ball bearing supported crankshaft
- Double walled heavy-duty tank with in tank fuel strainer
- 49-state compliant engine
See full description
Price for all four:
$677.96
Accessories We Recommend
This is a carousel with auto-rotating slides. Activate any of the buttons to disable rotation. Use Next and Previous buttons to navigate, or jump to a slide with the slide dots.
See All Horizontal Engines
See All Honda Engines Horizontal Engines
Currently Viewing This Product
Specifications
Specifications
Honda Engines, HONDA 160CC OHV ENGINE, Engine Displacement 163 cc, Engine Type GX Series OHV Commercial-duty, Shaft Diameter 3/4 in, Model# GX160UT2XQC9
Honda Engines, HONDA GC160 ENGINE - BLACK, Engine Displacement 160 cc, Engine Type GC Series OHC Residential-duty, Shaft Diameter 3/4 in, Model# GC160LAMHAB-BLK
Honda Engines, HONDA V-TWIN HORIZ 630CC HXQZB3 Engine Displacement 688 cc, Engine Type GX Series OHV V-twin Commercial-duty, Shaft Diameter 1 in, Model# GX630RHXQZB3
Honda Engines, HONDA V-TWIN HORIZ 690CC RHVXE, Engine Displacement 688 cc, Engine Type GX Series OHV V-twin Commercial-duty, Model# GX690RHVXE2
Engine Displacement
Same
163 cc
160 cc
688 cc
688 cc
Engine Type
Same
GX Series OHV Commercial-duty
GC Series OHC Residential-duty
GX Series OHV V-twin Commercial-duty
GX Series OHV V-twin Commercial-duty
Shaft Diameter
Same
3/4 in
3/4 in
1 in
Tapered
Shaft Length
Same
2.43 in
1.89 in
2.9 in
3 in
Start Type
Same
Recoil
Recoil
Electric
Electric
Shaft Keyway
Same
0.25 in
0.18 in
0.25 in
-
Net Torque
Same
7.6 ft-lbs.
6.9 ft-lbs.
35.6 ft-lbs.
35.6 ft-lbs.
Crankshaft
Same
Q-type
M-type
Q-type
V-type
PTO Height
Same
4.17 in
4.17 in
5.25 in
5.25 in
Cylinders (qty.)
Same
1
1
2
2
Cylinder Bore
Same
Cast Iron
Aluminum
Cast Iron
Cast Iron
Net Power Output
Same
4.8 HP
4.6 HP
20.8 HP
22.1 HP
Compression Ratio
Same
9:1
8.5:1
9.3:1
9.3:1
Fuel Tank
Same
Yes
Yes
No
No
Fuel Tank Capacity
Same
3.3 qt
1.9 qt
-
-
Oil Capacity
Same
0.59 qt
0.61 qt
2.1 qt
2 qt
Low Oil Shutdown
Same
Yes
No
Oil Alert
Yes, level indicator
Shaft Rotation (From PTO Shaft Side)
Same
Counter Clockwise
Counter Clockwise
Counter Clockwise
Counter Clockwise
Governor System
Same
Centrifugal Mechanical
Centrifugal Mechanical
Mechanical
Mechanical
Ignition System
Same
Electronic
Electronic
Electrical, Digital CDI W/variable Ignition Timing
Electrical, Digital CDI W/variable Ignition Timing
Carburetor
Same
Float, Inner Vent
Float
2 Barrel, Fuel-cut Solenoid, Inner Vent
Horizontal, Two-barrel Butterfly Valve, Internal Vent
Lubrication System
Same
Splash
Splash
Forced Lubrication
Forced Lubrication
Auto Compression Release
Same
Yes
Yes
Yes
Yes
Cooling System
Same
Air
Air
Air
Air
Bore
Same
2.7 in
2.5 in
3.1 in
3.06 in
Stroke
Same
1.8 in
2 in
2.8 in
2.81 in
Air Cleaner Type
Same
Cyclone
Single Element
Dual Element
Dual Element
Choke Control
Same
Manual
Manual
Manual
Manual
Throttle Control
Same
Remote
Manual
Manual
Manual
Fuel Filter
Same
Yes
Yes
Yes
Yes
Muffler Included
Same
Yes
Yes
No
No
Low Oil Alert
Same
-
No
Yes
Yes
Bearing Type
Same
-
Standard
Ball
Ball
Charging System Amps
Same
-
-
17
3
