Hobart Champion Elite 260 Arc Welder/Generator with 23 HP Kohler Gas Engine and Electric Start — 40–260 Amp DC Output, 11,000 Watt AC Power, Model# 500577

Item# 98639
Hobart Champion Elite 260 Arc Welder/Generator with 23 HP Kohler Gas Engine and Electric Start — 40–260 Amp DC Output, 11,000 Watt AC Power, Model# 500577

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

Hobart Champion Elite 260 Arc Welder/Generator with 23 HP Kohler Gas Engine and Electric Start — 40–260 Amp DC Output, 11,000 Watt AC Power, Model# 500577

Click or Tap image to Zoom

  • Versatile 2-in-1 unit with generator/welder capabilities
  • 41in.L x 20in.W x 28in.H unit is just under 3 1/2ft. long and weighs less than most competitive units
  • Portable, engine-driven solution with 23 HP Kohler twin cylinder, 4-cycle OHV, industrial air-cooled engine
  • Delivers up to 11,000 Watts of AC generator power to run tools, worklights or backup power during an outage
  • 9,500 continuous watts power generation

See full description

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Accessories

  • Warranty

  • Compare

Product Summary

The 2-in-1 versatility of the Hobart® Champion™ Elite 260 Arc Welder/Generator with Kohler Engine can simultaneously handle welding jobs and act as a generator to provide on-site power for tools and more. This compact, portable unit can be used as a 260 Amp DC welder or an 11,000 Watt generator, and is ideal for a wide variety of applications including: maintenance/repair, farm/ranch, fabrication, structural, steel work, general construction, emergency power and more. Comes with Hobart 5/3/1 limited warranty; engine warranted separately by manufacturer.

What's Included

  • (1) Welder/generator

Features + Benefits

  • Versatile 2-in-1 unit with generator/welder capabilities
  • 41in.L x 20in.W x 28in.H unit is just under 3 1/2ft. long and weighs less than most competitive units
  • Portable, engine-driven solution with 23 HP Kohler twin cylinder, 4-cycle OHV, industrial air-cooled engine
  • Delivers up to 11,000 Watts of AC generator power to run tools, worklights or backup power during an outage
  • 9,500 continuous watts power generation
  • 100% duty cycle
  • 40–260 Amp DC output range
  • Designed for stick welding with quick and easy arc starts
  • Can weld up to 1/2in. thick steel in a single pass
  • Delivers up to 15% more power for DC stick welding than a 225 Amp welder/generator
  • Quick-set amperage control provides easy setup and adjustments to get you welding faster
  • Auto-idle for increased fuel savings and reduced noise
  • Heavy-duty construction with fully enclosed engine design, large battery and rugged electrical connections and wiring
  • Includes built-in digital hour meter to assist you in keeping current on scheduled maintenance
  • Extra-large 12-gallon fuel capacity for increased runtimes
  • Low oil pressure shutdown protects the engine
  • Includes two 50 Amp/240V receptacles and 2 Duplex 120V GFCI protected outlets
  • Fully enclosed case design reduces noise and provides added weather protection
  • Sight gauge makes it easy to check fuel levels
  • "No tools" oil change and standard hour meter help maintain routine scheduled oil servicing
  • Required welding cables (Item#s 628510 or 628511) sold separately
  • Optional running gear wheel kit (Item# 42541) sold separately

Key Specs

AttributeSpecification

item#

98639

Brand

Hobart

Manufacturer's Warranty

1 year Limited Warranty

Ship Weight

5.1 LB
AttributeSpecification

Max. Weld Thickness

0.5 in

Duty Cycle

100 %

Weldable Materials

Steel

Min. Amps

40

Reviews

Questions & Answers

1 Review This action will navigate to reviews.

Questions

1–3 of 3 Questions
Sort by:

  1. Can both 240v outlets be used at the same time

    1 answer

    1. Both 240V outlets can be used at the same time as long as the load does not exceed 50 amps per outlet and a total of 9,500 running watts.

      Helpful?

  2. How long can the leads be?

    1 answer

    1. The recommended cables for this unit are our item #628510 and #628511. The #628510 set has a 20' electrode cable with holder and 15' work cable with clamp. Item #628511 has 50' cables for both the electrode and holder and work cable with clamp.

      Helpful?

  3. Hobart 260 Arc Can you run this at DC-? Can you use this for weld gouging? Is there anything else different from this model to the 225?

    Can you run this at DC-? Can you use this for weld gouging?
    Is there anything else different for the 225 Amp model other then the extra 35 amps?

    1 answer

    1. This unit has a DC output for stick welding, but has an AC power input.

      It has not been tested for weld gouging so it is not recommended for use in that application.

      The difference between this unit and the 225 amp model, item 42542, is that this unit has a 35 amp greater output and a digital fuel gauge in the display.
