The minimum HP would depend on what pressure you are going to run the pump at. If you are running the pump at the maximum 23 GPM at the maximum 2500 PSI, it would require 38 PTO HP. If you are running it at 23 GPM at 1500 PSI it would be 23 HP. You would figure 1 HP per GPM for every 1500 PSI. Anything below 38 HP would work with the pump.
Free Gift Card Details
$100 Order
$250 Order
$500 Order
$1000 Order
- The promotion will be automatically applied on the Shopping Cart page.
- To qualify for this offer, your order subtotal must equal $100 or more. Excludes gift cards, free item offers, warranties, Advantage memberships, tax and shipping.
- Free gift cards will be issued in the form of e-gift cards only, not physical gift cards.
- E-gift cards will be sent to the email address used in your billing address when your order ships or is picked up.
- Free e-gift cards expire 10/01/26.
- Promo code not valid on prior purchases or on Honda and STIHL products and cannot be combined with other promotional offers.
- Valid online and in participating retail stores.
- Limited-time offer. Subject to change without notice.
GRH Hydraulic PTO Tractor Pump — 23 GPM, Model# CB-P90LJ53S33BB

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

Click or Tap image to Zoom
This item is no longer available.
- Self-adjusting wear plates seal off leakage and offset any wear or expansion that may occur during the life of the pump
- High tensile aluminum housing, minimum gear clearance and cast iron endplates for durability
- Internal splined shafts go all the way through and are supported on both sides by roller bearings
- #16 SAE inlet port and two #12 SAE outlet ports
- Includes #12 SAE to 3/4in. NPTF female adapter
See full description
Description
Key Specs
Reviews
Q & A
Accessories
Warranty
Compare
Product Summary
What's Included
- (1) Hydraulic PTO tractor pump
Downloads
Features + Benefits
- Self-adjusting wear plates seal off leakage and offset any wear or expansion that may occur during the life of the pump
- High tensile aluminum housing, minimum gear clearance and cast iron endplates for durability
- Internal splined shafts go all the way through and are supported on both sides by roller bearings
- #16 SAE inlet port and two #12 SAE outlet ports
- Includes #12 SAE to 3/4in. NPTF female adapter
- For proper operation reservoir size should at least be as large as the output of the pump
Key Specs
| Attribute | Specification |
|---|---|
item# | 68585 |
Brand | GRH |
Manufacturer's Warranty | 12 months limited parts / No labor |
Ship Weight | 38.2 LB |
Max. PSI | 2,250 |
| Attribute | Specification |
|---|---|
Max. Flow Rate | 23 GPM |
Shaft Diameter | 1.37 in |
Shaft Type | Splined |
Material | Multiple |
Dimensions L x W x H (in.) | 9 x 6.5 x 6.5 in |
Reviews
Questions & Answers
Questions
-
· 4 years ago
What is the minimum PTO HP to run this pump?
1 answer-
ProductExpert6· 4 years ago
Helpful?
-
-
· 4 years ago
Will this run at 1000 pto rpm - 18hp diesel
1 answer-
ProductExpert7· 4 years ago
Yes, this can run at 1000 RPM. This max speed is 1100 RPM.
Helpful?
-
-
· 6 years ago
What is the direction of rotation required, looking toward front of tractor?
1 answer-
ProductExpert12· 6 years ago
When looking toward the front of the tractor, the rotation is clockwise.
Helpful?
-
-
· 6 years ago
GPM @ 540 RPM?
1 answer-
ProductExpert12· 6 years ago
This pump produces 12.5 GPM at 540 RPM.
Helpful?
-
