The welder is able to be used with spool gun model 1027-1398 (12 ft) or model 1027-1399 (25 ft). Please contact the manufacturer direct for pricing and availability.
ESAB, Rebel EMP 235ic Multi-Process Welder, Volts 120/230 Max. Amps 250 Mig Ready, Model# 0558012702
This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.
Click or Tap image to Zoom
$3399.99
- Exlcusive sMIG Technology - innovative "smart-MIG" feature continuously learns and adapts to the operator's welding technique to provide a stable arc and superior, repeatable welds; increases productivity for the experienced welder, and reduces training time for novice welders
- Innovative Color LCD display has larger display screen and higher pixel density to provide a more clear view of the TFT screen than other light industrial welders; loaded with exclusive features: on-demand availability of the user's manual, listing of spare parts - all in multiple languages
- Power to Perform - have the confidence with Rebel 235ic to run the full range of .035 in. wire- short arc and spray transfer. Also up to .045 in solid wire and up to .052 in. cored wire. Plus, rods up to 5/32 in. and TIG rods up to 3/16 in.
- 110V and 230V dual input voltage
- Trigger lock
Prop 65 Warning: See Details
See full description
See All MIG + Flux Core Welders
See All ESAB MIG + Flux Core Welders
Currently Viewing This Product
Specifications
Specifications
ESAB, Rebel EMP 235ic Multi-Process Welder, Volts 120/230 Max. Amps 250 Mig Ready, Model# 0558012702
Lincoln Electric LE31MP 120V 140 Amp Multi-Process Welder – MIG, Flux Core, Stick & TIG Welding Machine, Portable DC Welder with 60% Duty Cycle, 1/4" Steel Capacity, DIY & Professional Use, Model #K3461-1
Klutch MIG/Flux-Core Multi-Process Welder with Inverter Technology, 120 Volts, 140 Amp Max.
Hobart Handler 125, 120V, 130 Amp, Flux Core Welder, MIG-Ready Welder, Model# 500573
Volts
Same
120/230
120
120
120
Max. Amps
Same
250
140
140
130
Power Type
Same
DC
DC
DC
AC
Multi-process
Same
Yes
Yes
No
No
Spool Gun Included
Same
No
No
No
-
Welding Processes
Same
Flux-Core, MIG, Stick, TIG
Flux-Core, MIG, Stick, TIG
Flux-Core, MIG
Flux-Core, MIG-Ready
Max. Weld Thickness
Same
0.5 in
0.25 in
0.188 in
0.31 in
Max. Welding Wire Diameter
Same
0.052 in
0.035 in
0.035 in
0.03 in
Duty Cycle
Same
CC: Stick - 120 VAC - 85 Amps At 23.4 V - 40% Duty Cycle | CC: Stick - 230 VAC - 210 Amps At 28.4 V - 40% Duty Cycle | CC: TIG - 120 VAC - 130 Amps At 15.2 V - 40% Duty Cycle | CC: TIG - 230 VAC -
Mig: 60% At 95a; Stick: 60% At 80a; Tig: 60% At 115a
30%
25% At 80a; 60% At 50a; 100% At 40a
Weldable Materials
Same
Mild Steel, Steel, Aluminum
Mild Steel, Stainless Steel, Aluminum
Steel
Steel, Stainless Steel
Min. Amps
Same
5
80
30
25
Wire Feed Speed Control
Same
Yes
Yes
Yes
Yes
Cart Included
Same
No
No
No
No
Mig Ready
Same
Yes
Yes
Yes
Yes
Power Cord Length
Same
10 ft
10 ft
6.5 ft
6 ft
Clamp Cable Length
Same
6.5 ft
10 ft
6.5 ft
8 ft
Electrode Cable Length
Same
13 ft
10 ft
0 ft
-
Regulator and Gas Hose Included
Same
Yes
Yes
Yes
No
Shielding Gas Required
Same
Yes
Yes
No
No
Product Weight
Same
53.0000 lb
46.0000 lb
24.2000 lb
lb
Dimensions L x W x H (in.)
Same
26.5 x 19.5 x 11.5 in
18.12 x 9.0 x 13.62 in
18.0 x 8.5 x 13.0 in
19.4 x 10.0 x 13.5 in
