Endurance Marine Stainless Steel 24 Volt DC Powered Drum Winch, 2500 Watt Electric Motor, 4000-Lb. Pulling Capacity, Model# EDM2500W-015SS

Item# 97262
Endurance Marine Stainless Steel 24 Volt DC Powered Drum Winch, 2500 Watt Electric Motor, 4000-Lb. Pulling Capacity, Model# EDM2500W-015SS

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

Endurance Marine Stainless Steel 24 Volt DC Powered Drum Winch, 2500 Watt Electric Motor, 4000-Lb. Pulling Capacity, Model# EDM2500W-015SS

Click or Tap image to Zoom

$6988.50

  • Shipping:

    Factory shipped

    Heavy/large item. Lift gate service available.

  • Store Pickup:

    Not available - online only
  • Stainless steel 24V DC electric drum winch is a popular winch style for boat anchors
  • 4000-lb. line pull capacity
  • Powered by 2500 Watt vertically mounted, permanent magnet, heavy-duty motor
  • Dual direction solenoid with up/down switch
  • Winch is easy to install and to control by one person

See full description

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Warranty

  • Compare

Product Summary

The Endurance Marine Stainless Steel 24 Volt DC Powered Drum Winch is a very popular style of anchor winch and now it is even more affordable for all boaters. This anchor winch is compact, suitable for both anchoring in fresh water and offshore fishing. Ideal for large wells with the option to alter the angle of the motor and gearbox to the drum. The motor shroud, drum and shaft of the winch are made from marine grade quality stainless steel. The compact, fully sealed gearbox is driven by a vertically mounted, permanent magnet, heavy-duty motor. This winch comes with a dual direction solenoid with up/down switch and is easy to install and to control by one person. This type of drum winch has many other applications in the automotive, industrial, material handling, and mining. Please note: this is a large winch weighing 262 lbs. and measures 36in. x 30in. x 30in.

What's Included

    (1) Drum winch with 24V DC electric motor (1) Circuit breaker dual direction switch (1) Dual directional solenoid (1) Under surface mounting plate

Downloads

Product Manual

Features + Benefits

  • Stainless steel 24V DC electric drum winch is a popular winch style for boat anchors
  • 4000-lb. line pull capacity
  • Powered by 2500 Watt vertically mounted, permanent magnet, heavy-duty motor
  • Dual direction solenoid with up/down switch
  • Winch is easy to install and to control by one person
  • Motor shroud, drum and shaft are made from marine grade stainless steel

Key Specs

AttributeSpecification

item#

97262

Brand

Endurance Marine

Manufacturer's Warranty

1 year limited warranty

Ship Weight

262.0 LB

Horsepower

3.5 HP

Capacity (Line Pull)

4,000 lb

Application

Marine

Gear Type

Worm
AttributeSpecification

Line Speed

45 ft./min.

Gear Ratio

45:1

Rope Length

328 ft

Rope Diameter

1/2 in

Brake Type

Self-Locking

Remote

Yes

Freespooling

No

Mounting Hardware Included

Yes
