Endurance Marine Stainless Steel 12 Volt DC Powered Drum Winch, 1000 Watt Electric Motor, 1000-Lb. Pulling Capacity, Model# EDM1000-012SS

Item# 97259
Endurance Marine Stainless Steel 12 Volt DC Powered Drum Winch, 1000 Watt Electric Motor, 1000-Lb. Pulling Capacity, Model# EDM1000-012SS

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

Endurance Marine Stainless Steel 12 Volt DC Powered Drum Winch, 1000 Watt Electric Motor, 1000-Lb. Pulling Capacity, Model# EDM1000-012SS

Click or Tap image to Zoom

$3000.00

  • Shipping:

    Factory shipped

  • Store Pickup:

    Not available - online only
  • Stainless steel 12V DC electric drum winch is a popular winch style for boat anchors
  • Surface mount with power out/power in
  • 1000-lb. line pull capacity, rated on the second wrap on the drum
  • Powered by 1000 Watt vertically mounted, permanent magnet, heavy-duty motor
  • Dual direction solenoid with up/down switch

See full description

Complete Your Solution

  • Endurance Marine Stainless Steel 12 Volt DC Powered Drum Winch, 1000 Watt Electric Motor, 1000-Lb. Pulling Capacity, Model# EDM1000-012SS
  • Portable Winch Hitch Mounting Plate Anchor, Fits 2in. Ball Hitches, Model# PCA-1261
Price for all two:

$3050.00

Frequently Bought Together

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Accessories

  • Warranty

  • Compare

Product Summary

The Endurance Marine Stainless Steel 12 Volt DC Powered Drum Winch is a very popular style of anchor winch and now it is even more affordable for all boaters. This anchor winch is compact, with power out/power in, suitable for both anchoring in fresh water and offshore fishing. Ideal for small or narrow anchor wells with the option to alter the angle of the motor and gearbox to the drum. The drum and shaft of the winch are made from marine grade quality stainless steel. The compact, fully sealed gearbox is driven by a vertically mounted, permanent magnet, heavy-duty motor. This winch comes with a dual direction solenoid with up/down switch and is easy to install and to control by one person. This type of drum winch has many other applications in the automotive, industrial, material handling and mining markets.

What's Included

    (1) Drum winch with 12V DC electric motor (1) Circuit breaker dual direction switch (1) Dual directional solenoid (1) Under surface mounting plate

Downloads

Product Manual

Features + Benefits

  • Stainless steel 12V DC electric drum winch is a popular winch style for boat anchors
  • Surface mount with power out/power in
  • 1000-lb. line pull capacity, rated on the second wrap on the drum
  • Powered by 1000 Watt vertically mounted, permanent magnet, heavy-duty motor
  • Dual direction solenoid with up/down switch
  • Winch is easy to install and to control by one person
  • Drum and shaft are made from marine grade stainless steel

Key Specs

AttributeSpecification

item#

97259

Brand

Endurance Marine

Manufacturer's Warranty

1 year limited warranty

Ship Weight

35.0 LB

Capacity (Line Pull)

1,000 lb

Application

Marine

Gear Type

Worm
AttributeSpecification

Line Speed

40 ft./min.

Gear Ratio

121:1

Brake Type

Self-Locking

Remote

Yes

Freespooling

No

Fairlead Type

Other

Mounting Hardware Included

Yes

Reviews

Questions & Answers

Questions

1–3 of 3 Questions
Sort by:

  1. Is the motor stainless also?

    1 answer

    1. The motor is made from powder coated steel. The motor does need to be steel as it has a magnetic field. The motor does have a stainless steel shroud that covers the motor.

      Helpful?

  2. How many feet of rope an what size rope does it handle

    1 answer

    1. The drum capacity is 130 meters of 8mm nylon plus 8 meters of 6/8mm short link chain.

      Helpful?

  3. when dropping the anchor ...does it free fall? or slowly ctank in reverse? I want it to drop fast ..so I don't drift off the spot in 100ft of water..

    1 answer

    1. The drum winch would have a 20mm (0.79") line speed per minute.
