DuroMax, 274cc Electric Start Gasoline Engine, Engine Displacement 274 cc, Engine Type Gasoline Engines, Shaft Diameter 1 in, Model# XP9HPE

Name: DuroMax, 274cc Electric Start Gasoline Engine, Engine Displacement 274 cc, Engine Type Gasoline Engines, Shaft Diameter 1 in, Model# XP9HPE
Brand: DuroMax
SKU: 5183969
Price: 389.99 USD
Availability: InStock

Item# 5183969

Click or Tap image to Zoom

$389.99

Quantity

Save to List

Shipping:
Free shipping (lower 48 states) - Factory shipped
Store Pickup:
Not available - online only

274cc 4-Stroke OHV Engine
Large 1.3 Gallon Fuel Tank
Runs on Standard 87 Octane Gasoline
Electric Start Key Switch Box
EPA and CARB Approved for Safe Mandated Use

Prop 65 Warning: See Details

See full description

Product Summary

The DuroMax XP9HPE is one of our most compact and lightweight engines available, but don’t let the size fool you. This powerful 274 cc 4-stroke OHV engine has plenty of power for multiple light duty applications including go karts, pressure washers, trailer-mounted mobile carwashes, log splitters, rototillers, cultivators, and water/trash transfer pumps. The XP9HPE is equipped with convenient features such as a large 1.3-gallon gas tank for longer runtimes, a quick and easy electric start, and an E-Z pull recoil starter for startup flexibility. This engine is EPA and CARB approved for safe mandated use.

What's Included

(6) DuroMax XP9HPE Engine, 12V Battery Leads, Spark Plug Wrench, Keys, Oil Funnel, and Owner’s Manual

Features + Benefits

274cc 4-Stroke OHV Engine
Large 1.3 Gallon Fuel Tank
Runs on Standard 87 Octane Gasoline
Electric Start Key Switch Box
EPA and CARB Approved for Safe Mandated Use
Applications: Go Karts, Pressure Washers, Trailer Mounted - Mobile Carwashes, Log Splitters, RotoTillers - Cultivators, Water/Trash Transfer Pump

Key Specs

Attribute	Specification
item#	5183969
Brand	DuroMax
Manufacturer's Warranty	3 year limited warranty
Ship Weight	60.0 LB
Engine Displacement	274 cc
Engine Type	Gasoline Engines

Attribute	Specification
Shaft Diameter	1 in
Fuel Type	Gasoline
Start Type	Electric and Recoil
Shaft Keyway	.276inch in
Product Weight	45.0000 lb
Dimensions L x W x H (in.)	16.4 x 13.2 x 15.1 in

Reviews

Questions & Answers

Questions

1–7 of 7 Questions

9 months ago

Is this a true 1 inch shaft or 25mm .98 ? Is the shaft bolt standard or metric ?

1 answer
1. ProductExpert11

  9 months ago

  The shaft diameter is 25 MM (0.98"). The shaft will have a tapped end measurement of M10x1.25-6. Usable shaft length 63 MM (2.48").

  Helpful?
2 years ago

Whats the engine rpm? Is this a 12 volt starter?

1 answer
1. ProductExpert11

  2 years ago

  The maximum RPM is 3600 RPM. The engine will have a 12 volt electric starter. The 12 volt battery leads are included.

  Helpful?
2 years ago

Can you upgrade carburetor on motor

1 answer
1. ProductExpert37

  2 years ago

  The manufacturer does not recommend any modifications to this engine.

  Helpful?
3 years ago

horse power

1 answer
1. ProductExpert38

  3 years ago

  This engine is rated at approximately 8 HP.

  Helpful?
3 years ago

Does this engine have a charging system for battery?

1 answer
1. ProductExpert38

  3 years ago

  This engine is equipped with a charging system.

  Helpful?
3 years ago

I wanted to know what is the whole engine demension. what the width, leight and height?

1 answer
1. ProductExpert5

  3 years ago

  The dimensions are 16.4" L x 13.2" W x 15.1" H.

  Helpful?
3 years ago

How long is the shaft it states it’s a 1” diameter and also states the key way size?

1 answer
1. ProductExpert11

  3 years ago

  The length of the shaft is 2.48 " L .

  Helpful?

Warranty

Manufacturer's Warranty

3 year limited warranty
