Coxreels 100 Series Hand Crank Hose Reel, 3/4in. x 100ft. Hose Capacity, 4000 Max. PSI, Model# 117-5-100

Item# 114034
"Coxreels 100 Series Hand Crank Hose Reel, 3/4in. x 100ft. Hose Capacity, 4000 Max. PSI, Model# 117-5-100"
Coxreels 100 Series Hand Crank Hose Reel, 3/4in. x 100ft. Hose Capacity, 4000 Max. PSI, Model# 117-5-100

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

Coxreels 100 Series Hand Crank Hose Reel, 3/4in. x 100ft. Hose Capacity, 4000 Max. PSI, Model# 117-5-100

Click or Tap image to Zoom

$274.99

  • Shipping:

    Factory shipped

  • Store Pickup:

    Not available - online only
  • Solid brass, 90+ full-flow NPT swivel for simple, seal maintenance and fast, easy hose installation. No need to remove reel from its mount
  • Solid, one-piece U-shaped frame design
  • Heavy-duty CNC robotically spun and ribbed discs with rounded edges for greater strength and durability
  • Adjustable tension brake adjusts the speed of the draw to desired preference and prevents reel from free wheeling during operation, transport or storage
  • High-quality steel construction with long-lasting, chip-resistant and rust-inhibiting powder coat finish

See full description

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Warranty

  • Compare

Product Summary

The Coxreels® 100 Series Hand Crank Hose Reel is a lightweight, compact and versatile reel that performs at working pressures up to 4000 PSI. The sturdy U-shaped frame, all streel construction and CNC spun discs make this reel ideal for heavy-duty commercial and industrial applications. Save time and effort while increasing the safety of your work environment with this professional-grade hand crank hose reel.

What's Included

    (1) Hank crank hose reel

Features + Benefits

  • Solid brass, 90+ full-flow NPT swivel for simple, seal maintenance and fast, easy hose installation. No need to remove reel from its mount
  • Solid, one-piece U-shaped frame design
  • Heavy-duty CNC robotically spun and ribbed discs with rounded edges for greater strength and durability
  • Adjustable tension brake adjusts the speed of the draw to desired preference and prevents reel from free wheeling during operation, transport or storage
  • High-quality steel construction with long-lasting, chip-resistant and rust-inhibiting powder coat finish
  • Direct hand crank for easy mechanical retraction
  • Hose not included

Key Specs

AttributeSpecification

item#

114034

Brand

Coxreels

Manufacturer's Warranty

2 year limited warranty

Ship Weight

35.0 LB

Hose Diameter

3/4 in

Hose Length

100 ft

Max. PSI

4,000
AttributeSpecification

Hose Material

PVC

Hose Outlet Size

3/4 in. NPT

Reel Inlet Size

3/4 in. NPT

Auto Rewind

No

Whip Hose Included

No

Product Weight

35.0000 lb

Dimensions L x W x H (in.)

17.0 x 23.25 x 18.0 in

Reviews

Questions & Answers

1 Review This action will navigate to reviews.

Questions

Warranty

Manufacturer's Warranty

2 year limited warranty
