California Air Tools, 10 Gal 2 Hp Air Compressor Automatic Drain Valve, Horsepower 2 HP, Air Tank Size 10 Gal, Volts 110 Model# 10020CHAD

Item# 6203845
California Air Tools, 10 Gal 2 Hp Air Compressor Automatic Drain Valve, Horsepower 2 HP, Air Tank Size 10 Gal, Volts 110 Model# 10020CHAD

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

California Air Tools, 10 Gal 2 Hp Air Compressor Automatic Drain Valve, Horsepower 2 HP, Air Tank Size 10 Gal, Volts 110 Model# 10020CHAD

Click or Tap image to Zoom

$551.99

  • Shipping:

    Factory shipped

  • Store Pickup:

    Not available - online only
  • Ultra Quiet only 70 Decibels
  • Oil-Free Pump for Less Maintenance & Costs
  • 10.0 Gallon Steel Tank
  • Portable and easy to store - 82.75 lbs
  • Powerful 2.0 HP (Rated / Running) Motor

  • Prop 65 Warning: See Details

See full description

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Warranty

  • Compare

Product Summary

The California Air Tools 10020CHAD Ultra Quiet Oil-Free Air Compressor is designed to be one of the quietest 2.0 Hp air compressors in the industry having only 70 decibels of sound. The Powerful 2.0 HP motor operates at only 1680 RPM creating less noise and less wear. SP Series of Ultra Quiet Air Compressor Motors have been designed to increase duty cycle and allow for longer continuous run times. The Oil-Free Dual Piston Pump System is engineered for high performance and durability. The CAT-10020CHAD Air Compressor has a Oil-Free Dual Piston pump designed to have a life cycle before wear of 3000 Plus hours compared to other comparable air compressors with life cycles of 500 hours or less. The Oil-Free pump allows for use in a variety of temperatures (cold starts) and uneven terrains (no oil in the pump). The Easy Start Valve feature allows for a easier start up using less starting amps. The Easy Start Valve releases a small amount of air from the pump at start up to produce a no-load condition allowing the motor to spin freely. This no-load start up requires less amps for a easier start up in cold temperatures. The large low profile 10 Gallon Steel Horizontal Air Tank makes storing under a bench, desk or shelf very easy. The factory installed California Air Tools EZ-1 Automatic Drain Valve has been designed to eliminate manually draining your air compressor air tank. The manually set timer allows you to set the time for both the frequency and duration of the draining process. The 10020CHAD is designed for the person looking for Power, Air Flow, Less Service and Maintenance with at Least 30% Less Noise!

What's Included

    (1) Air Compressor

Features + Benefits

  • Ultra Quiet only 70 Decibels
  • Oil-Free Pump for Less Maintenance & Costs
  • 10.0 Gallon Steel Tank
  • Portable and easy to store - 82.75 lbs
  • Powerful 2.0 HP (Rated / Running) Motor
  • 6.40 CFM @ 40 PSI
  • 5.30 CFM @ 90 PSI
  • Maximum Pressure - 125 PSI
  • Two Pressure Control Gauges
  • One 1/4" Universal Quick Connectors
  • Low amp draw - 15.0 Amps - 110 Volts 60 Hertz
  • Thermal Overload Protector
  • Less time to fill the tank - Only 120 Seconds
  • Low Vibration - Motor Speed of 1680 RPMS
  • Less Heat - Dissipates heat more efficiently
  • Extra Large Dual Piston Pump for increased Compression
  • Extra Long Pump Life of over 3000 Hours
  • Oil-Free pump allows you to use in different temperatures & terrains
  • Limited Warranty 1 Year

Key Specs

AttributeSpecification

item#

6203845

Brand

California Air Tools

Manufacturer's Warranty

1 year limited warranty

Ship Weight

78.0 LB

Air Tank Size

10 Gal
AttributeSpecification

Volts

110

Horsepower

2 HP

Product Weight

75.0000 lb

Dimensions L x W x H (in.)

19.0 x 15.0 x 26.5 in

Reviews

Questions & Answers

Questions

Warranty

Manufacturer's Warranty

1 year limited warranty
