AIMS Power Charger 120V AC, Input Selectable 12V/75A or 24V/32.5A Output, CON120AC1224DC

Item# 7532974
New1 Included
AIMS Power Charger 120V AC, Input Selectable 12V/75A or 24V/32.5A Output, CON120AC1224DC

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

AIMS Power Charger 120V AC, Input Selectable 12V/75A or 24V/32.5A Output, CON120AC1224DC

Click or Tap image to Zoom

$211.22

  • Shipping:

    Factory shipped

  • Store Pickup:

    Not available - online only
  • Large charging capacity design 75 Amp for 12Vdc charges a 100 amp hour battery in under an hour up to 90% charge
  • Power supply up to 75 amps at 12Vdc
  • Three stage smart charger with variable charging voltage algorithm for maximizing  battery life (bulk, absorb and float)
  • 4 pre-programmed charging algorithms using the dip switches for the most common charging profiles
  • Charges lead acid, AGM, GEL and LiFPO4 batteries

  • Prop 65 Warning: See Details

See full description

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Warranty

  • Compare

Product Summary

The AIMS Power 75-Amp Converter/Battery Charger automatically detects 12VDC and 24VDC battery banks and accepts a broad 70 to 145 VAC input range, giving it the latitude to work with generators, shore power, and unstable utility supply across a wide set of applications. It charges open lead acid, AGM, gel, and LiFePO4 batteries, and its 75-amp output brings a 100 amp-hour battery to roughly 90 percent charge in under an hour, making it well suited to RVs, boats, campers, service vehicles, and off-grid banks that need to recover quickly between uses. Protection circuitry covers reverse polarity, over-voltage, under-voltage, short circuit, and over-temperature conditions. The unit is listed to UL 458 and CSA 22.2 and carries a two-year manufacturer's warranty.

What's Included

    (1) Converter/Battery Charger (1) Instruction Manual

Features + Benefits

  • Large charging capacity design 75 Amp for 12Vdc charges a 100 amp hour battery in under an hour up to 90% charge
  • Power supply up to 75 amps at 12Vdc
  • Three stage smart charger with variable charging voltage algorithm for maximizing  battery life (bulk, absorb and float)
  • 4 pre-programmed charging algorithms using the dip switches for the most common charging profiles
  • Charges lead acid, AGM, GEL and LiFPO4 batteries

Key Specs

AttributeSpecification

item#

7532974

Brand

AIMS Power

Manufacturer's Warranty

No limited warranty

Ship Weight

7.0 LB

USB Ports (qty.)

0

AC Outlets (qty.)

0

Included (qty.)

1

Product Type

Other

Cable Length

4 ft

Application

AC Converter / Battery Charger
AttributeSpecification

LED Indicators

Yes

Low Battery Protection

Yes

High Temperature Protection

Yes

Overload Protection

Yes

Low Voltage Protection

Yes

Cables Included

Yes

Battery Included

No

Product Weight

10.2500 lb

Dimensions L x W x H (in.)

3.25 x 6.5 x 6.75 in
