IPA Hydraulic Oil Filtration/Transfer System — 26 GPM Pump, Model# 9046H

Item# 89092
IPA Hydraulic Oil Filtration/Transfer System — 26 GPM Pump, Model# 9046H

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

IPA Hydraulic Oil Filtration/Transfer System — 26 GPM Pump, Model# 9046H

Click or Tap image to Zoom

  • 26 GPM pneumatic pump removes emulsified water from hydraulic oil systems
  • System includes water and particulate blocking filters
  • 22ft. of 1in. dia. hoses offers extended reach
  • Special tank access wands are included for added versatility
  • Quick disconnect hoses and adapters for easy setup

See full description

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Accessories

  • Warranty

  • Compare

Product Summary

This IPA Hydraulic Oil Filtration/Transfer System helps you restore hydraulic systems that are plagued by moisture. Reclaim dirty hydraulic and motor oils, or quickly transfer and fill hydraulic systems. The system can also be used on CNC equipment for extracting, filtering chips and filling oil reservoirs. The fully assembled cart includes a pneumatic pump, filters and gauges. 11ft.L x 1in. dia. intake hose, 11ft.L x 1in. dia. output hose, 5ft. rigid fiberglass input wand, 5ft.3/4in. flexible access wand, 5ft.1/2in. flexible access wand, 1in. open end hose adapters, removable ball valve inline hose adapter, chassis ground cable, extra 10 Micron water blocking filters, and drain pan.

What's Included

  • (1) Fully assembled cart
  • (1) Pneumatic pump
  • (1) Set of filters and gauges
  • (1) 11ft.L x 1in. dia. intake hose
  • (1) 11ft.L x 1in. dia. output hose
  • (1) 5ft. rigid fiberglass input wand
  • (1) 5ft.3/4in. flexible access wand
  • (1) 5ft.1/2in. flexible access wand
  • (1) Set of 1in. open end hose adapters
  • (1) Ball valve inline hose adapter
  • (1) Chassis ground cable
  • (1) Extra 10 Micron water blocking filter
  • (1) Drain pan

Features + Benefits

  • 26 GPM pneumatic pump removes emulsified water from hydraulic oil systems
  • System includes water and particulate blocking filters
  • 22ft. of 1in. dia. hoses offers extended reach
  • Special tank access wands are included for added versatility
  • Quick disconnect hoses and adapters for easy setup
  • Includes detachable drain pan, panel mount regulator, controls, filter and pressure gauges
  • Primary and Secondary filters clear ends on each hose to view condition of fluid during transfer
  • Cart design provides mobility and allows spill-free, complete drain down after use

Key Specs

AttributeSpecification

item#

89092

Brand

IPA

Manufacturer's Warranty

24 months parts / 12 months labor

Ship Weight

100.0 LB

Flow

26 GPM
AttributeSpecification

Suction Hose Length

1 in

Discharge Hose Length

11 in

Air Inlet Size

1 in. NPT

Dimensions L x W x H (in.)

24 X 24 X 60 in

Reviews

Questions & Answers

Questions

1–2 of 2 Questions
Sort by:

  1. Where do you get filters. Oil and diesel?

    1 answer

    1. The filters would be available on our website www.northerntool.com. See item #67098 or 67095 for a diesel filter and item #56980 for a hydraulic filter online. These filters would also be available at any hydraulic or diesel supply store that also carries filters. You would need to be sure you are purchasing the appropriate filters for your intended use of this system for hydraulic oil or diesel.

      Helpful?

  2. Can this be used to filter clean diesel fuel?

    1 answer

    1. The 9046H comes standard with filters which are designed for filtering Hydraulic Oil. However, the user can remove the hydraulic filters and install spin-on type diesel filters within a few minutes.

      Helpful?
