Ingersoll Rand Air Impact Wrench, 1/2in. Drive, 6 CFM, 1350 Ft./Lbs. Max Torque, Model# 2235TiMax

Item# 48418
"Ingersoll Rand Air Impact Wrench, 1/2in. Drive, 6 CFM, 1350 Ft./Lbs. Max Torque, Model# 2235TiMax"
Ingersoll Rand Air Impact Wrench, 1/2in. Drive, 6 CFM, 1350 Ft./Lbs. Max Torque, Model# 2235TiMax

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

Ingersoll Rand Air Impact Wrench, 1/2in. Drive, 6 CFM, 1350 Ft./Lbs. Max Torque, Model# 2235TiMax

Click or Tap image to Zoom

$299.99

  • Shipping:

    Free shipping (lower 48 states) - Available now
    $19.99 Same Day

  • Store Pickup:

    2 in stock at Fredericksburg VA - Pickup in under 1 hr

  • Delivers 1350 ft./lbs. of nut-busting torque; 930 ft./lbs. of max. reverse torque and 900 ft./lbs. of forward torque
  • 8500 RPM no-load speed
  • 1220 IPM
  • Finely tuned twin hammer impact mechanism delivers heavy-duty torque
  • Titanium hammercase, steel wear plate and composite housing for toughness in harsh environments

See full description

Complete Your Solution

  • Ingersoll Rand Air Impact Wrench, 1/2in. Drive, 6 CFM, 1350 Ft./Lbs. Max Torque, Model# 2235TiMax
  • Ingersoll Rand Air Tool Oil, 1 Pint
  • Ingersoll Rand Impact Sockets, 13-Pc. Set, 1/2in.-Drive, Deep Well, SAE, Model# SK4H13L
  • Ingersoll Air Care Kit, Model# 105-LBK1
Price for all four:

$455.96

Frequently Bought Together

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Accessories

  • Warranty

  • Compare

Product Summary

The Ingersoll Rand 1/2in. Air Impact Wrench is a powerful, durable and reliable workhorse that can handle the toughest fastening tasks. Loosen the toughest bolts with 1350ft./lbs. of nut-busting torque and 930ft./lbs. of reverse torque, powered by a finely tuned twin hammer impact mechanism. The 2235TiMax is built with a titanium hammercase, steel wear plate and composite housing that protects the tool from the harshest environments. From the garage to the most demanding industrial sites, there is no job that will stand in its way.

What's Included

    (1) 1/2in. air impact wrench

Downloads

Product Manual
Play Item Video

Features + Benefits

  • Delivers 1350 ft./lbs. of nut-busting torque; 930 ft./lbs. of max. reverse torque and 900 ft./lbs. of forward torque
  • 8500 RPM no-load speed
  • 1220 IPM
  • Finely tuned twin hammer impact mechanism delivers heavy-duty torque
  • Titanium hammercase, steel wear plate and composite housing for toughness in harsh environments
  • Weighs only 4.6 lbs. so you can work faster and for longer periods of time
  • 6 CFM air consumption
  • 1/4in. inlet
  • 3/8in. minimum hose size

Key Specs

AttributeSpecification

item#

48418

Brand

Ingersoll Rand

Manufacturer's Warranty

2 year limited warranty

Ship Weight

5.45 LB

Drive Size

1/2 in

Max. RPM

8,500

Impacts Per Minute

1,220

Max. Reverse Torque

930 ft-lbs.

Max. Forward Torque

900 ft-lbs.

Min. Working Torque

450 ft-lbs.

Max. Working Torque

930 ft-lbs.
AttributeSpecification

Air Consumption

6 cfm

CFM at Load

6

Nut Busting Torque

1,350 ft-lbs.

Max. PSI

90

Air Inlet Size

1/4 in

Hammer Mechanism

Yes

Min. Hose Size

3/8 in

Reversible

Yes

Case Included

No

Bolt Capacity

0.75 in

Tool Length

7.6 in

Reviews

Questions & Answers

42 Reviews This action will navigate to reviews.

Questions

1–8 of 8 Questions
Sort by:

  1. If this impact wrench consumes 6 CFM at 90 psi, would an air compressor that produces 5.5 CFM at 90 psi be enough?

    1 answer

    1. It could work at 5.5 CFM at 90 PSI intermittently. It would require a higher CFM if a more continuous operation is needed.

      Helpful?

  2. How many decibels does this wrench produce?

    1 answer

    1. The impact wrench would have a decibel rating of 98 DB.

      Helpful?

  3. does it come with the air hose connection or no

    1 answer

    1. The air impact does not come with a quick connect air fitting.

      Helpful?

  4. 6 CFM at what pressure?

    1 answer

    1. The average air consumption rating on the gun will be 6 CFM at 90 PSI.

      Helpful?

  5. country of origin specify on the tool name plate

    1 answer

    1. This is manufactured in the United States.

      Helpful?

  6. What's the difference in " nut busting 1350 ft/lbs torque versus 930 ft/lbs max reversing torque on Model#2235 air impact wrench.

    1 answer

    1. “Nut-busting” torque refers to the tool’s ability to remove a bolt that has been tightened down using methods other than the tool itself. For the “nut-busting” torque, a bolt is tightened with a torque wrench calibrated to 1350 ft-lbs, then removed with the tool being tested. In this case, the 2235TiMAX is able to remove the bolt, so the advertised “nut-busting” torque is 1350 ft-lbs. The max reverse torque is the maximum amount of torque that the tool is able to deliver in reverse.

      Helpful?

  7. Does this impact have a variable speed trigger?

    1 answer

    1. This Ingersoll Rand Impactool Air Impact Wrench does not have a variable speed trigger.

      Helpful?

  8. Where is this tool made?

    1 answer

    1. This Ingersoll Rand Impactool Air Impact Wrench is made in the United States.

      Helpful?
