GRH Hydraulic PTO Tractor Pump — 40 GPM, Model# CB-P160LJ53S33BB

Item# 68291
GRH Hydraulic PTO Tractor Pump — 40 GPM, Model# CB-P160LJ53S33BB

This is a carousel with one large zoomable image and a track of thumbnails on the left. Select any of the thumbnail buttons to change the zoomable image on the right. If a thumbnail is a video or 360 degree image thumbnail, or the last thumbnail in the list, the button will open the product media modal.

GRH Hydraulic PTO Tractor Pump — 40 GPM, Model# CB-P160LJ53S33BB

Click or Tap image to Zoom

  • Handles pressures up to 2250 PSI max.
  • SAE O-ring ports: inlet #20 1 5/8in. - 12, drain outlet #16 15/16in. -12 plus auxiliary outlet, #12 11/16in -12
  • Includes #20 SAE to 2in hose adapter and #16 SAE to 1in female pipe
  • Easy installation using torque arm restraint
  • Reservoir size should at least be as large as the output of the pump

See full description

  • Description

  • Key Specs

  • Reviews

  • Q & A

  • Accessories

  • Warranty

  • Compare

Product Summary

This direct drive GRH Hydraulic PTO Tractor Pump delivers 40.1 GPM at 1000 RPM and over 20 GPM at 540 RPM when operating at 1000 PSI. The pump has roller bearing bearing construction, pressure balanced, self-adjusting wear plates and an internally splined 1 3/8in. dia., 21-tooth drive shaft, so it doesn't need a gear box.

What's Included

  • (1) PTO tractor pump

Downloads

Product Manual

Features + Benefits

  • Handles pressures up to 2250 PSI max.
  • SAE O-ring ports: inlet #20 1 5/8in. - 12, drain outlet #16 15/16in. -12 plus auxiliary outlet, #12 11/16in -12
  • Includes #20 SAE to 2in hose adapter and #16 SAE to 1in female pipe
  • Easy installation using torque arm restraint
  • Reservoir size should at least be as large as the output of the pump

Key Specs

AttributeSpecification

item#

68291

Brand

GRH

Manufacturer's Warranty

12 months limited parts / No labor

Ship Weight

43.0 LB

Max. PSI

2,250
AttributeSpecification

Max. Flow Rate

40 GPM

Shaft Diameter

1.37 in

Shaft Type

Splined

Material

Multiple

Dimensions L x W x H (in.)

9 x 6.5 x 6.5 in

Reviews

Questions & Answers

Questions

1–5 of 5 Questions
Sort by:

  1. Hello I was just making sure this pump is 540 tractors pto type?

    1 answer

    1. This pump operates at a max 540 RPM's.

      Helpful?

  2. Made in China???

    1 answer

    1. This item is manufactured in China.

      Helpful?

  3. The picture shows a 540 RPM shaft size but the listing says it is a 21 tooth spline which would be a 1000 shaft size. Do you know which PTO shaft it fits. 1000 or 540 Thanks

    1 answer

    1. The RPM rating is 540.

      Helpful?

  4. So the reservoir size needs to be 40 gallons for this 40 GPM pump? Is that US Gals?

    1 answer

    1. It would be for US gallons.

      Helpful?

  5. What is minimum PTO horsepower required for this and besides the spline what keeps this in place on tractor.

    1 answer

    1. There is no minimum horsepower requirement, the motor must be capable of rotating the pump at the rated operating speed of 1000 RPM. To keep the pump in place, a bracket will need to be fabricated to fit the tractor, otherwise it is just attached by the spline.

      Helpful?

Warranty

Manufacturer's Warranty

12 months limited parts / No labor
